Advantages and Applications of Integrated Fire Pump Systems

It’s a customized EJ fire pump set consisting of electric pump, jockey pump along with control panel, and accessories. It is equipped with priming tank for doing negative suction.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar (40-300 psi)
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set includes diesel engine pumps, electric pumps and jockey pumps.
In various fields, our products find applications in large hotels, hospitals, schools, office buildings, supermarkets, commercial residences, subway stations, train stations, airports, various transportation tunnels, petrochemical plants, thermal power plants,oil storage tanks, large warehouses, industrial and mining enterprises, seawater injection, etc.

Fire pump systems are comprised of various components, each playing a critical role in ensuring their proper function. Some of the key components include:

Fire Pump: This is the heart of the system, responsible for pressurizing the water and sending it to the fire protection devices.

Controllers: Controllers monitor the system, automatically starting the pump in response to a fire alarm signal and providing system status information.

Suction and Discharge Piping: Properly designed piping is essential for efficient water flow. Suction piping brings water to the pump, while discharge piping carries it to the fire protection devices.

Pressure Relief Valves: These safety valves release excess pressure to prevent damage to the system.

Valves: Various valves control water flow within the system, allowing for isolation, testing, and maintenance.

These components work in concert to provide reliable water distribution in case of a fire.

Diesel engine fire pump, as a fixed fire extinguishing equipment, has been widely used in fire diversion, especially in the case of no power supply or abnormal power supply and other emergencies, other diesel engines can also be equipped as power engines according to the needs of users.

Diesel engine fire pump unit is a kind of pump equipment that is widely used in fire protection, and it is more suitable for mobile work in fire pumps. In fact, it is driven by a diesel engine connected to the pump head of the fire pump. Compared with motor drive, it can be used in the field, mines, and places lacking power supply. It is also called a diesel engine pump or a diesel engine fire pump unit.

The diesel engine fire pump set has the characteristics of good starting performance, strong overload capacity, compact and reasonable structure, convenient maintenance, simple and reliable operation, etc. The unit is equipped with first-level protection functions for overspeed, low oil pressure, three engine failures, high water temperature, low oil level, and low battery voltage. At the same time, the fire pump can be connected with the customer’s automatic fire alarm device or the centralized control cabinet of the fire protection system, and the characteristics of the diesel engine fire pump group can realize the function of remote monitoring.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar
The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations.

A fire pump system typically includes the pump itself, a driver (usually an electric motor or diesel engine), a controller, and various accessories like suction and discharge piping, check valves, and pressure gauges.

The diesel engine fire pump has the characteristics of good starting performance, serious load operation, compact structure, time-saving and labor-saving maintenance, simple application, and high level of automatic control technology. It is a security monitoring device with reliable performance.

In smart buildings, the latest trends in fire pump technology focus on integrating advanced sensors, IoT (Internet of Things) capabilities, and data analytics to enhance system performance and reliability. Smart fire pumps can communicate with building management systems (BMS) to provide real-time data on pump status, water flow, pressure, and other key parameters. This data can be used for predictive maintenance, alerting operators to potential issues before they become critical. Additionally, smart pumps can adjust their operation based on real-time conditions, optimizing energy use and ensuring the most efficient response during a fire emergency. These technologies enhance safety and align with the broader trend toward more intelligent, automated, and energy-efficient building systems.

With the characteristics of full sealing, no leakage and corrosion resistance, fire pumps are widely used in environmental protection, water treatment, fire protection and other departments. They are ideal pumps for building non-leakage, non-pollution civilized workshops and civilized factories. Our commonly used fire pumps are electric fire pumps and diesel engine fire pumps. The difference between the two is that the electric fire pump needs power system supply. If the power is cut off, the diesel engine fire pump can be started at any time to make up for the original position of the electric fire pump.

EDJ series fire pump set consists of Electric pump + Diesel pump + Jockey pump and all accessories.
The pressure switch and control cabinet can automatically turn on/off three pumps-the electric pump and jockey pump operate when there is electricity and the diesel pump activates when the power cuts.
Flow Capacity Range:50-5000 GPM
Pressure Range:4-14 Bar
Power Range：4-325 KW

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

XBC series diesel engine fire-fighting pump group is a new-style fire-fighting equipment (“equipment” thereafter) developed by this Co. in accordance with GB6245-98 “Performance Requirement and Testing Method of Fire-fighting Pumps” and NFPA20 “Installation of Centrifugal Fire-fighting Pumps” etc. standards and, upon the
fitted fire-fighting pumps (single-stage single-suction type, single-stage double-suction type and sectional multistage type), can be divided into XBC-IS, XBC-S and XBC-D three sub series. The equipment has a wide range of pressure and temperature and can be used for almost every occasion necessary for fire-fighting. The diesel engine fitted with the equipment is an excellent product domestic or imported, features good starting performance, strong overload capacity, compact structure, easy maintenance and use and high degree of automation. The equipment is really a fire-fighting one advanced and reliable in performance. The reasonable use and serious maintenance of the fire pump is the most important prerequisite for ensuring the normal and reliable operation of the pump, giving full play to the emergency function and prolonging the service life. In order to make the pump operator familiar with its structural characteristics, grasp the use and maintenance methods, and make good use of the pump, we have prepared this manual for the operator reference

“Fire-fighting gas top-pressure water supply equipment is usually composed of basic components such as air-pressure water tanks, control cabinets, top-pressure gas storage systems, and decompression release devices; in the fire-fighting state, compressed gas is charged into the air-pressure water tank to replace the fire-fighting water storage in the tank. , and always maintain the rated working pressure of fire protection, and the fixed fire water supply equipment that supplies water to the fire pipe network.”

As the name suggests, fire pumps are used in fire protection. They are divided into different types according to different classification methods. They are fully sealed and leak-free. They are used in environmental protection, water treatment, fire protection and other departments to pump various liquids. They are created The ideal pumps for non-leakage, civilized workshops and civilized factories are similar to the pumps for fire protection systems, but the head and flow are different.

– Protection of Critical Data Infrastructure: Ensuring reliable fire protection for servers, storage, and network equipment.
– Non-Disruptive Fire Suppression: Implementing systems that minimize the risk of data loss or equipment damage.
– Redundant Systems for Reliability: Providing redundant fire protection systems to ensure continuous operation.
– Compliance with Data Center Safety Standards: Adhering to fire safety regulations specific to data centers and IT infrastructure.

Diesel fire pumps offer distinct advantages over other types of fire pumps, such as electric or jockey pumps. Unlike electric pumps, which rely on grid power and may be vulnerable to power outages, diesel fire pumps can operate independently, making them suitable for use in areas with unreliable electricity or during emergencies. Jockey pumps, on the other hand, are typically used to maintain pressure in fire sprinkler systems but may not provide the same flow rates or firefighting capacity as diesel fire pumps.

In fire protection systems, various types of fire pumps are used. Fire pumps are classified as horizontal split case, vertical split case, vertical in-line, vertical turbine, or end suction. These fire pumps may be powered by an electric motor, a diesel engine, or on rare occasion powered by a steam turbine.

Flow: 5-400L/s
Head: 3-20Bar
Material:
HT200, SS304, Bronze
Caliber:65-350mm
Pressure: 0.3~1.5MPa
Speed:740-2900r/min

Fire pumps have a wide range of uses. In addition to providing water for fire-fighting pipeline systems, they can also be used in industrial water supply. Fire pumps can also be used in urban water supply and drainage systems. There are other relatively long-distance water supply work, such as heating boilers, bathroom boilers, hot and cold water circulation pressurization of multi-stage fire pump boilers, etc.

This integrated electric control fire pump unit features a high-efficiency pump design and advanced automatic control system, ensuring stable operation under high-pressure water supply conditions. The powerful motor drive delivers continuous high head and large flow output, meeting various demanding fire protection standards. With multi-point pressure monitoring and intelligent feedback adjustment, the system maintains consistent water pressure, greatly enhancing fire suppression efficiency and operational reliability.

The fire pump is all made of polymer materials, so it has many characteristics such as cleanliness, good safety sealing, corrosion resistance, etc. It is a product that is believed in many fields at present. It has a long service life and can make the best use of it without wasting money. It is suitable for fire-fighting engineering in steel, metallurgy, electric power, petroleum, chemical, construction, port and other operations and emergency water supply for blast furnaces, continuous casting, converters, etc. Water supply works.

The size and capacity of a firefighting pump depend on factors such as the size of the area to be protected, the potential fire hazard, and the water supply available. Calculating factors such as flow rate, pressure requirements, and the distance water needs to be delivered can help determine the appropriate pump size and capacity.

UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

EDJ Fire fighting package set

120≤ Q≤1000GPM
H＜150m
The EDJ fire pump group is composed of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the stabilized pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

The EDJ fire pump group is composed of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the stabilized pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar (40-300 psi)
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set includes diesel engine pumps, electric pumps and jockey pumps.
In various fields, our products find applications in large hotels, hospitals, schools, office buildings, supermarkets, commercial residences, subway stations, train stations, airports, various transportation tunnels, petrochemical plants, thermal power plants,oil storage tanks, large warehouses, industrial and mining enterprises, seawater injection, etc.

The EE Pump Set is designed according to the customer’s specifications which is including 2 electric pumps and 1 control panel.
