Composition of Standard EJ Fire Pump Set

Horizontal and vertical fire pumps differ in their physical orientation, and the choice between them depends on the available space and installation requirements. Horizontal fire pumps are positioned parallel to the ground and are commonly used in facilities with ample floor space. Vertical fire pumps, on the other hand, are designed to be installed in a space-saving, vertical orientation. This makes them suitable for facilities with limited floor space, such as high-rise buildings.

Vertical pumps are often used in skyscrapers, where space is at a premium. Both types of pumps are equally effective, and the choice between them is typically influenced by the layout and structural constraints of the building.

Fire-fighting package set water supply equipment manufactured by is referred to as
“dual-power”, “Fire Pump Set” hereinafter as “dual-power”, “Fixed Fire Pump Installation
Standard” and “Standard for the Fixed Fire Pump Installation Standard” of the
American Fire Protection Association in accordance with China Standard GB27898.5-2011
Fixed Fire-fighting Water Supply Equipment Part 5 “Fire Dual-power Installation of
Stationary Pumps for Fire Protection -2016 design and manufacture. Comply with the
latest Chinese national standard CCCF certification requirements and obtain the
certificate. Dual power is one of the reliable products in fire fighting water supply equipment.

• Automatic switching between three pumps, when the electric fire pump fails, the diesel engine backup pump will automatically start
• Works even with power outages
• Adopt high-quality NSK bearing, wear-resistant mechanical seal or packing seal
• Product parameters available upon request

It’s a customized EJ fire pump set consisting of electric pump, jockey pump along with control panel, and accessories. It is equipped with priming tank for doing negative suction.

The minimum fire rated pressure of ED small fire fighting package set water supply equipment is 3 bar and the minimum fire rated capacity is 25 GPM. ED small fire fighting package set water supply equipment includes at least two power or power source driven pumping units, pressure tanks, pipes, valves and accessories, measurement and control instruments, control cabinets, outdoor rain cover, etc.
Motor: Three-phase asynchronous squirrel-cage motor independently developed and manufactured by our company, which can be controlled in production time and greatly shorten the whole set production time.
Diesel Engine: According to the different parameters of customers, we will choose diesel engines with high cost performance ratio. The main brands are QuanChai, Weichai, ShangChai, FAWDE, Cummins, etc.
Electric Pumps: Electric pumps can use vertical in-line pumps, horizontal end-suction pumps, vertical multi-
stage pumps, horizontal multi-stage pumps, split casing pumps and so on according to the different flow and head of customers.
Diesel Pumps: Diesel pumps can use vertical in-line pumps, horizontal end-suction pumps, vertical multi-
stage pumps, horizontal multi-stage pumps, split casing pumps and so on according to the different flow and head of customers.
Electronic Components: The main electric components is CHNT, if Schneider or other brand electrical are need, should mention it before place the order.
Safety Valve plays a safety protection role in the system. When the system pressure exceeds the prescribed value, the safety valve opens, and a part of the gas/fluid in the system is discharged into the atmosphere/pipeline, so that the system pressure does not exceed the allowable value, so as to ensure that the system does not cause accidents due to excessive pressure.
Pressure Tank: Water is a non-compressible medium. Generally speaking, the pressure drop of fire-fighting pipe network is normal. However, the pressure drop is very slow, the total loss of water in the pipe network isnot large, and the frequent change of pressure in the pipe network leads to frequent start-up and shutdown of pumps. Especially when the power of equipment is high, it will cause great impact on pressure sensors, relaysand motors, thus affecting the performance and life whole equipment. Therefore, it is necessary to choose the right volume of the pressure tank.

EDJ fire pump is the main pump used for various fire hydrants and sprinkler fire pumps; it is suitable for various fire boosting and pressure stabilizing pumps; various villas, community and other fire protection systems; industrial and civil building fire protection systems; suitable for Various oil depots, oil loading and unloading docks, logistics parks and other places with high fire protection requirements.

The EEJ fire pump set is composed of two electric pumps + one jockey pump. The motor of the electric pump is directly connected to the ISW pump head. The jockey pump adopts CDL pump, adopts high-quality NSK bearing and wear-resistant mechanical seal, which is suitable for any emergency firefighting occasion. . Products can be customized according to their own needs.

Industrial manufacturing plants often deal with hazardous materials, heavy machinery, and complex processes, making fire safety a critical concern. Fire pumps are essential in these facilities for delivering sufficient water pressure to fire suppression systems like sprinklers, standpipes, and specialized suppression systems, such as foam or gas-based systems used for chemical fires. Jockey pumps help maintain pressure in these extensive systems, ensuring they are always ready to activate immediately. In many industrial plants, fire pumps need to handle large volumes of water to cover expansive areas like production floors, storage facilities, and hazardous material zones. Additionally, fire suppression systems must be designed to address specific risks, such as oil-based fires, electrical hazards, or flammable chemicals. Fire pumps in these environments require regular maintenance and testing to ensure they remain reliable, especially given the high risk of equipment malfunction or accidents in such settings. Integrating the fire pump system with automated fire detection systems, alarms, and emergency response protocols is critical for minimizing damage and protecting workers in the event of a fire.

The electric motor fire pump is an important water supply equipment in the fire protection system. The electric motor fire pump has a wide range of head, flow and power, and can be used in many environments. Providing sufficient water supply is the key to ensure emergency use.

EJ dual-power fire pump group is used for various fire hydrants and sprinkler fire main pumps; it can more reliably ensure water safety in the event of a fire. EJ dual-power fire pump set is designed and manufactured by Beide Technology Co., Ltd. in accordance with GB 27898.5-2011 Fixed Fire Water Supply Equipment Part 5 <>. It meets the new 3CF requirements and has obtained 3CF certification for fire protection products. EJ small dual-power diesel engine fire pump is used for various fire hydrants and sprinkler fire main pumps; it is suitable for various fire boosting and pressure stabilizing pump occasions; various villas, residential areas and other fire protection systems; industrial and civil building fire protection systems ;Applicable to various oil depots, oil loading and unloading docks, logistics parks and other places with high fire protection requirements.

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

CDL stainless steel vertical multistage pump is especially suitable for boiler feed water, and can also be widely used in pressure vessel water supply, hot water circulation, high-rise building water supply, farmland irrigation, fire pressurization, hydraulic flushing, food, brewing, medicine, chemical industry, aquaculture , environmental protection, chemical process and machine tool supporting industries, as the power equipment for water supply and drainage.

Diesel engine fire pump is a kind of fire-fighting equipment that we often see and often use in our life. The diesel engine fire pump has the characteristics of good starting performance, strong overload capacity, compact internal structure, convenient maintenance, simple operation and high degree of automation. It is a very reliable fire fighting equipment.

answer:
1. The raceways of the inner and outer rings are peeled off, cracked or severely worn.
2. The rolling body is out of round or the surface is peeled off, with cracks.
3. The cage is seriously deformed or worn, and the rolling elements cannot be fixed.
4. There is vibration or noise when turning, and there is reverse reversal or braking when stopping.
5. The fit clearance of the bearing exceeds the maximum value of the specified clearance.

Fire Pump Packages
Fire pump package comprises a combination of electric motor driven pump, diesel engine driven and electric motor driven jockey pumps that supply for fire suppression systems.
Fire pump package is required to comply with Local Civil Defense Authority regulations and International Codes of Practice e.g. National Fire Protection Association (NFPA).

Types of pumps used for fire service include: end suction, horizontal split case, vertical split case, vertical inline and vertical turbines.

Components
1. Diesel pump: flow is the same with electric pump. It connects the pump set with high elastic coupling or universal joint.
2. Jockey pump: vertical, small flow, head is higher than electric or diesel pump.
3. Control panel: control the pumps automatically with overload, overcurrent protection.
4. Accessories: Suction pipe, Discharge pipe with flange, Battery, Gate valve, Check valve, Flexible expansion joints, Pressure switches, Pressure gauge, base frame etc.

The fire pump set adopts OTS pump.Series OTS pumps are single stage,double suction with horizontally split casings .They are suitable pumping unsettled water, clean water ,non-drinkable or hydrocarbon at a temperature not exceeded 105C.They are adoptable in water works irrigation and drainage pumping stations,fire fighting systems, marine applications as well as refinery industry,etc.

Flow: 14-2700 GPM
The EJ Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The diesel engine fire pump unit is directly driven by the diesel engine fire pump, and it is a mechatronic equipment that can start and complete the water supply in a short time. The diesel engine pump set is driven by a diesel engine without external power supply. Diesel pumps are suitable for fire water supply occasions such as agricultural irrigation, emergency rescue, smelting, hangars, petrochemical oil depots, power plants, liquefied gas stations, and textiles. Especially in the case of no electricity and dissatisfaction with the grid, choosing a diesel engine-driven water pump is the safest choice.

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions

The intelligent diesel engine water pump products produced by our company are equipped with an unattended intelligent system as standard configuration. The product has the characteristics of mature technology, high degree of automation, superior performance, complete protection functions, reasonable structure, simple installation and high cost performance. At the same time, in order to meet the different needs of users and reasonable investment, the products are divided into multiple application series such as fire pumps, industrial emergency pumps, agricultural water pumps, marine water pumps, trailer mobile water pump stations, etc., which can be linked and switched with electric fire pumps. Supporting water pumps: single-stage fire pump, multi-stage fire pump, single-stage split double-suction fire pump.

1.Flow: 50-5000GPM
2.Head: 3-20Bar
3.Speed: 740-2900r/min
4.Power: Electric pump: 1.5-710 kw, Jockey pump: 0.55-160kw
The EEJ Fire Pump System includes two electric pumps and a jockey pump.With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression.

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

A multistage pump is a multistage centrifugal pump in which two or more impellers are installed on the pump shaft and connected in series to work together. A horizontal multistage centrifugal pump refers to a multistage pump in which centrifugal pumps with two or more impellers are combined. The multistage centrifugal pump is characterized by high efficiency and energy saving, wide range of use, special purpose, stable operation, long service life, convenient installation and maintenance, etc.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The size of a fire pump is determined through hydraulic calculations based on the specific fire protection requirements of the building. Factors considered include the building’s height, area, occupancy type, and the required flow rate and pressure to meet fire protection standards.

Lifecycle management involves:

Regular Maintenance: Implement a scheduled maintenance program to keep the pump in optimal condition.
Upgrades and Retrofits: Upgrade or retrofit components as technology advances or as system requirements change.
End-of-Life Planning: Plan for the eventual replacement of the pump system, ensuring minimal disruption to fire protection coverage.
Performance Monitoring: Continuously monitor performance to identify when parts or the entire system need replacement or overhaul.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar (40-300 psi)
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set includes diesel engine pumps, electric pumps and jockey pumps.
In various fields, our products find applications in large hotels, hospitals, schools, office buildings, supermarkets, commercial residences, subway stations, train stations, airports, various transportation tunnels, petrochemical plants, thermal power plants,oil storage tanks, large warehouses, industrial and mining enterprises, seawater injection, etc.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min
