DJ fire pump set loading container

ED fire-fighting complete sets of water supply equipment are usually equipped with electric pumps, diesel pumps, and it is very important for fire-fighting installations to jockey pumps, so that the pressure level of the system can be maintained without starting the main pump. ED fire-fighting complete set of water supply equipment has reasonable layout, firm installation, reliable connection, compact structure, neatness and convenient maintenance. ED fire water supply equipment is used in hotels, shops, stores, warehouses, workshops, residences and other places with high fire protection requirements.

Fire pumps are more commonly used in commercial and industrial settings. Residential buildings often rely on municipal water pressure for fire protection. However, in some cases, residential structures with specific design requirements may incorporate fire pumps.

The minimum fire rated pressure of small fire fighting package set water supply equipment is 6 bar, and the minimum fire rated capacity is 25 GPM. EDJ small fire fighting package set water supply equipment includes at least two power or power source driven pumping units, pressure tanks, pipes, valves and accessories, measurement and control instruments, control cabinets, outdoor rain cover, etc.

EDJ electric diesel fire pump set is the pump used for various fire hydrants and sprinkler fire main pumps; it is suitable for various fire boosting and pressure stabilizing pump occasions; various villas, residential areas and other fire protection systems; industrial and civil building fire protection systems ;Applicable to various oil depots, oil loading and unloading docks, logistics parks and other places with high fire protection requirements.

Many people buy fire pumps for the first time and don’t know how to choose a fire pump. They know very little about fire pumps and don’t know how to choose. So today, on the issue of fire pump selection, here is a explanation for everyone to help you better choose a more competitive fire pump.

The fire pump is used to transport various liquids. It is an ideal pump and fire system for building civilized factories, non-leakage, and non-polluting civilized workshops. It is often installed on fire extinguishing systems, fire trucks or other fire-fighting facilities to transport water. Or a special pump for foam solution fire extinguishing. Pipeline fire pumps are widely used in water treatment, environmental protection, fire protection and other departments.

1. The fire pump should be capable of supplying the rated flow and pressure for a duration of two hours, at a rate of 150% of the rated capacity, and should not be affected by prolonged operation.

2. The fire pump should be able to start up automatically by a power source when activated.

3. All switches, gauges, alarms, controllers and monitoring systems should be certified to UL and FM standards.

4. The fire pump should be sized to meet the NFPA 20 standard for fire pump design.

5. The fire pump should be able to handle the maximum system flow and pressure required for the building.

6. The fire pump driver should match the requirements of the pump and meet NFPA 20 requirements for fire pump drivers.

7. The fire pump should be installed according to NFPA 20 standards for fire pump installation.

8. The fire pump should be tested and inspected in accordance with NFPA 25 standards for testing and inspection of fire pumps.

The pressure stabilizer pump is a kind of fire pump. It is used to stabilize the pressure of the automatic sprinkler system and the fire hydrant water supply system, so that the water pressure of the system is always in the required pressure state. Water volume and water pressure.

Fire pump refers to a clean water pump used for fire water supply, and a single water pump with a treatment medium temperature lower than 80 degrees and non-corrosive. The pump unit is a joint operation of multiple fire pumps to ensure the quantity and stability of water supply. The electric motor fire pump set adopts multiple fire water pumps powered by electric motors.

Features of diesel multi-stage pump:
1. Multiple impellers are combined in series, the output pressure is large, so the lift is high.
2. The shaft seal adopts packing seal or mechanical seal, the seal is safe and reliable, the structure is simple, and the maintenance is convenient and quick.
3. The shaft is a fully sealed structure, which ensures no contact with the medium, no rust, and long service life.

The diesel engine fire pump set has the characteristics of good starting performance, strong load capacity, compact and effective structure, convenient maintenance, simple and reliable use, etc. The generator set has maintenance functions such as speed limit, low oil level, repeated failed starts, high temperature, low oil level, and low battery voltage. At the same time, it can be connected with the customer’s automatic fire alarm system or the centralized control cabinet of fire-fighting facilities to establish a real-time monitoring function.

The electric fire pump set is a fire pump powered by an electric motor, and generally consists of a set of fire pumps, electric motors, control cabinets and auxiliary devices. Because the electric motor fire pump set is composed of these parts, it forms a powerful fire protection and power effect, and provides a strong water source support for various fire hydrant systems and sprinkler systems in the building.

Diesel pump is a pump powered by diesel engine, which completely reduces the labor intensity of workers, and it is convenient to use, move, install, rarely maintain, and stable performance

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

Fire pumps are an important part of the fire protection system, especially in high rise structures.In basic 400 – 500 or advanced water situations, fire pumps are important to distribute water into water lines and sprinkler systems where the water pressure of the fire fighting equipment cannot reach. Especially in low-rise structures, fire pumps are important for fire control.
Stylistically, fire protection is a dangerous activity, but without a well-designed and professionally installed system and pump, it certainly becomes more dangerous and commercial assets and lives are less at risk.

Packaging and delivery

Packaging details: standard export wooden cases or as required delivery detail: within 30 days

Specification

Compact structure, stable performance
Install and maintain conveniently
Mechanical or packing seal

Application

Use in fire system water supply, and also suitable for water supply plant, irrigation, drainage pumping plant, electric plant, air conditioning water supply, industry water supply, fire system, shipping industry, oil refining system, mining and other water supplying situations.

The function of diesel fire pump is very powerful, we can set the control time during use, for example: preheating in advance, preparatory lubrication or timing start. The use of high-tech has made some complicated and time-consuming things easier in the past. The preheating setting greatly reduces the preparation time for rescue, allowing firefighters to rescue the first time. In the face of disasters, time is money and time. is life.

XBC diesel engine fire pump set can also be equipped with other diesel engines as power engines according to user needs. It is mainly composed of diesel engine, fire pump, connection device, fuel tank, radiator, battery pack, intelligent automatic control panel, etc. Diesel engine fire pump series products have high efficiency, long operating life and high reliability (there is no failure of pneumatic seizure after a long period of inactivity).

DJ series fire pump set consists of Diesel pump + Jockey pump and all accessories.
The pressure switch and control cabinet can automatically turn on/off three pumps-the electric pump and jockey pump operate when there is electricity and the diesel pump activates when the power cuts.

Application areas: commercial, municipal and residential high-rise buildings, large industrial plants and warehouses, offshore and remote facilities, airports, power stations.
Industrial fields: various petroleum, petrochemical, chemical, oil fields, management bureaus, oil depots, oil terminals, oil refineries, offshore platforms, etc.; national grain depots, thermal power plants, steel mills, shipyards, paper mills, etc.;
Commercial fields: five-star hotels, hospitals, schools, supermarkets, office buildings, large commercial complexes, highway tunnels, subway stations, railway stations, airports; fire engineering companies;

Last month our customer from Ecuador ordered 2 sets EDJ fire pump set from our factory. The gpm and bar he needs is 350gpm@135psi, and he will use these two fire pump system in his factory.

EEDJ Fire Pump Package ,The equipment is designed to have 2 electric pumps. one duty and one standby and one diesel pump stand by function. The main pump runs normally, and the standby pump starts automatically after the main pump fault . The Jockey pump will start and stop based on the pipe pressure, Control panel site start.

1.Flow: 50-5000GPM
2.Head: 3-20Bar
3.Speed: 740-2900r/min
4.Power: Electric pump: 1.5-710 kw, Jockey pump: 0.55-160kw
The EEJ Fire Pump System is an innovative solution designed to enhance fire safety in various settings. With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression.Overall, the EEJ Fire Pump System is a reliable choice for safeguarding lives and properties, making it an ideal fire protection solution for commercial buildings, industrial facilities, and residential areas.

The fire pump’s pump casing should be regularly inspected for signs of corrosion, warping, and damage. The casing should also be visually inspected for leakage, and all fittings should be tested regularly to ensure they are properly sealed. All gaskets and seals should be checked for wear and replaced when needed. The impeller should be routinely checked to make sure it is free of debris and that all blades are in good condition. Any abnormal sound or vibration should be investigated immediately.

Electric fire pumps are driven by electric motors, and are divided into horizontal, vertical and many other structural varieties. The electric fire pump set has a small footprint, light weight, low noise, and good start-up and operation performance. Although electric fire pumps have the advantages of simple operation and maintenance, most fire protection system design specifications stipulate that when electric fire pumps are used, they should have the conditions for dual-circuit power supply, and diesel engine fire pumps are usually used as backup pumps.

1. Electric fire pump: various end suction pumps and split pumps.
2. jockey pump: vertical, small flow, higher lift than electric or diesel pumps.
3. Control panel: Automatically control the water pump with overload and overcurrent protection.
4. Accessories: suction pipe, discharge pipe with flange, battery, gate valve, check valve, flexible expansion joint, pressure switch, pressure gauge, base, etc.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

The ED Dual-Power Fire Pump System combines electric and diesel engine pumps to ensure uninterrupted fire protection and a reliable water supply. In the event of power outages or electrical failures, the diesel engine pump seamlessly takes over, guaranteeing continuous operation of the fire protection system. This dual-power configuration offers both reliability and flexibility, providing comprehensive coverage for fire safety needs. With smart controls and automatic switching mechanisms, the transition between electric and diesel engine pumps is seamless, minimizing system downtime. Equipped with advanced safety features, including monitoring and alarm systems, real-time status updates allow for prompt action in case of any irregularities.

Diesel fire pumps are ideal for applications where a separate pump room already exists or where the pump room is located on an exterior wall. Facilities using diesel fire pumps include warehouses, aircraft hangars and industrial facilities. Since they have a larger footprint than electric fire pumps, they are not suitable for installations where space is small. Unlike diesel pumps, electric fire pumps can be located inside buildings. Office buildings and apartments are often equipped with electric fire pumps. In addition, upper floors sometimes install an additional electric fire pump above ground or basement to increase water pressure.
