EDJ 500gpm@94m fire fighting package set-ZJBetter

Flow: 30-9000 GPM
Head: 3-20Bar
Speed: 740-2900r/min
Material: HT200, SS304, Bronze

The EJ Fire Pump Set is combined an electric pump and a jockey pump.

All places need to be equipped with fire-fighting facilities, and fire pumps are necessary water intake equipment for fire-fighting facilities. At least one or two fire pumps are equipped. Our commonly used fire pumps are electric fire pumps and diesel engine fire pumps. The difference between the two is The electric fire pump needs to be supplied by the power system. If the power is cut off, the diesel engine fire pump can be started at any time to make up for the original position of the electric fire pump.

Single-stage fire pumps have only one impeller, and multistage fire pumps can have two or more impellers. Because the pump core in them is different, the structure is different. The impeller of the multi-stage pump is more than that of the single-stage pump, which can achieve a larger head at the same flow rate. The multi-stage pump is the sum of the single-stage pumps, and the head and outlet pressure can be made very high.

Electric motor fire pumps are used in various water environments, not only for ordinary water supply but also as a good helper for fire water. The electric motor fire pump is manufactured with good structure and technology, with a wide range of performance, simple operation and long-term use. The electric motor fire pump is aimed at various fire water environments, so the selection should also be based on the actual demand environment, performance parameters, etc.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar 40-300 psi
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
5.Material：HT200 SS304 Bronze
6.Caliber：65-350 mm
7.Working Pressure：≤1.6 MPa
The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations.

A multistage pump refers to a pump with two or more impellers, which can absorb and press water in multiple stages, so as to lift the water to a high position. The lift can be increased or decreased according to the needs of the pump impeller. The multistage pump can be equipped with a four-stage motor by increasing the number of impellers when the single-stage pump head needs to be equipped with a two-stage motor, which can improve the service life of the pump and reduce the noise of the unit.

750gpm fire fighting package set

120≤ Q≤1000GPM
H＜150m
The EDJ fire pump group is composed of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the stabilized pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

DJ fire pump set loading container
400gpm 6.8 bar DJ fire pump set laoding container in factory

The EDJ fire pump set is composed of a fire pump, a dual-shaft extension motor and a diesel engine. One end of the output shaft of the dual-shaft extension motor is connected to the input shaft of the fire pump, and the other end of the output shaft of the dual-shaft extension motor is connected to the input shaft of the fire pump. One end of a clutch is connected, and the other end of the clutch is connected with the output shaft of the diesel engine. The fire water pump, the double-shaft extension motor, the clutch and the diesel engine are all fixed on the base. The double-shaft extension motor, the clutch and the diesel engine are respectively electrically connected with a control circuit through the action driving circuit. With dual-power fire pump, there is no need to configure a second fire pump, reducing floor space and manufacturing costs.

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

Diesel engine fire pump unit is a kind of pump equipment that is widely used in fire protection, and it is more suitable for mobile work in fire pumps. In fact, it is driven by a diesel engine connected to the pump head of the fire pump. Compared with motor drive, it can be used in the field, mines, and places lacking power supply. It is also called a diesel engine pump or a diesel engine fire pump unit.

The video displays EJ fire pump set is being tested. The system set is equipped with a priming tank and can do 2 to 3 meters negative suction.

Diesel engine fire pump can be used in fire water supply in warehouses, docks, airports and other occasions. We usually choose the appropriate diesel engine fire pump model and application according to the head, flow, power, medium properties, and required materials provided by the user. In order to avoid mistakes, the loss caused by the installation environment will be comprehensively considered to ensure stable and reliable efficiency.

Diesel engine fire pump is a kind of mechatronics equipment that is directly driven by diesel engine fire pump and can start and complete water supply in a short time. Diesel engine pump set is driven by diesel, no external power supply is required. Diesel engine pump is suitable for agricultural irrigation, emergency rescue, smelting, hangar, petrochemical oil depot, power plant, liquefied gas station, textile and other fire-fighting water supply occasions, especially in the absence of electricity, When the power grid is not satisfied, it is the safest choice to use a diesel engine to drive the water pump.

1. All personnel must be familiar with the operation manual and the safety regulations of the fire pump before use.

2. When the fire pump is in operation, no one should be allowed to approach the pump or the suction and discharge pipelines.

3. The suction and discharge pipelines should be inspected regularly to ensure that there are no blockages, as blockages can cause the pump to malfunction.

4. The pressure of the pump should be checked regularly to ensure that it is within the range specified by the manufacturer.

5. Before starting the fire pump, all valves in the suction and discharge pipelines must be checked to make sure they are open.

6. All safety devices should be checked regularly to make sure they are in good working condition.

7. The motor should be checked regularly to make sure it is in good working condition.

8. The fuel tank should be checked regularly to make sure it is filled with the correct type and amount of fuel.

9. The temperature of the pump should be checked regularly to make sure it is not too high.

10. If a fault is detected, the pump should be shut down and the fault should be rectified before it is restarted.

Choose the installation location: Ensure it’s a clean, ventilated, and non-flood-prone area.
Prepare a solid foundation: Use a robust concrete base to minimize vibration.
Follow manufacturer guidelines: Properly align and secure the pump and diesel engine.
Connect fuel supply and exhaust systems: Ensure safe fuel storage and proper exhaust ventilation.

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

It’s the 3D Display of Fire Pump Set and its working principle. The fire pump set is usually consisting of jockey, electric&diesel engine pump along with control panel and accessories.

Flow: 30-9000 GPM
Head: 3-20Bar
Speed: 740-2900r/min
Material: HT200, SS304, Bronze
The EJ Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations.

1.Electric pump, can use single stage pump, horizontal split case pump, end suction pump, multistage pump, material can be cast iron, stainless steel, and bronze impeller
2.Diesel engine pump, with capacity and head equal to electric pump, with fuel tank, water tank,fan
3.Jockey pump, horizontal or vertical, capacity will be small, but head should be higher than electric and diesel engine pump, this jockey pump is optional
4.Control panel: Auto Control for all pumps with overload, over current protection.
5.Accessories: valves, pressure vessel, Pressure Gauge, Pressure Sensor, Common Base plant

1.Flow：30-9000 GPM
2.Head： 3-20 Bar 40-300 psi
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water.

The EDJ Fire Pump system consists of diesel engine fire pumps, electric pump units, and pressure stabilizing pumps, creating an intelligent automatic fire water supply system. Our electric pump units come in various models, including single-stage pumps, horizontal split-case pumps, end-suction pumps, and multi-stage pumps, constructed with cast iron or stainless steel and equipped with efficient copper impellers for exceptional performance.
Whether it’s for buildings, factories, or warehouses, the EDJ fire pump system provides outstanding performance and reliability for your fire protection system, ensuring safety and security during fire emergencies!

Fire pump system is made of two Electric+Diesel+Jockey pump
The main eletric components is CHNT . If schneider or other brand electrical are need, should mention it before place the order
Diesel pumps can use vertical in- line pumps, horizontal end-suction pumps,vmultistage pumps, horizontal multi-stage pumps, split casing pumps and so on according to diffenent flow and head of customers

The fire pumps produced by our company are suitable for fire protection occasions such as warehouses, docks, airports, petrochemicals, power plants, liquefied gas, textiles, ships, oil tankers and so on.

Instructions for use:
Altitude: ≤1000m;
Ambient temperature: +5℃～+40℃;
Relative humidity: <= 90%.

Advancements in firefighting pump technology focus on improving efficiency, reliability, and safety. Some emerging trends include the development of more compact and lightweight pumps, integration of smart monitoring and control systems, and the use of alternative fuels for powering pumps, such as hydrogen or electric batteries.

The EDJ （Diesel Pump:XA, Electric Pump:XA）Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

There are many applications for fire pumps. Different motors are selected according to the flow rate and head size. The commonly used motors include electric motors and diesel engines, and domestic and foreign brands can match the application. The fire pump can choose vertical or horizontal structure according to the pipeline requirements, and the head size is also different. Finding a professional pump factory or company can reduce the probability of wrong selection, and at the same time take into account the on-site installation requirements and pipeline design.

1. Make sure all valves are open and the system is in good working order.

2. Check the fuel filter for any debris, and replace as needed.

3. Adjust the governor control to reduce the RPM of the engine, and limit fuel consumption.

4. Regularly inspect, clean and replace the air filter to ensure maximum efficiency.

5. Maintain the fuel injection system to minimize fuel wastage.

6. Use synthetic oil instead of petroleum-based engine oil.

7. Reduce the demand on the fire pump by using water pressure regulators or other available techniques.

8. Use the most efficient fuel type for the engine.

9. Use the most efficient nozzle size for the fire pump.

10. Use a variable frequency drive to reduce the engine speed and conserve energy.

EJ fire pump set producting
150gpm 7bar electric fire pump with jockey pump
Assemble in our workshop
