EDJ Fire Fighting Pump System with Diesel Pump+Electric Pump+Jockey Pump

Fire pump is one of the fire-fighting equipment, its function is mainly used to transport water or other fire-extinguishing liquid for fire-fighting. Pumping water with equipment such as fire pumps has a very high water delivery efficiency. There are many types of fire pumps, and the air pumping methods of different fire pumps are also different. Sprinklers, fire hydrants, and water cannons and window sprays commonly used in business have the same pump-starting principle, but the fire-fighting linkage principle is different.

Instructions for use:
Altitude≤1000m;
Ambient temperature: +5℃～+40℃;
Relative humidity: <= 90%. Scope of application of fire pump set: Equipment suitable for fire protection occasions such as warehouses, docks, airports, petrochemicals, power plants, liquefied gas, textiles, ships, oil tankers, etc.

The electric fire pump set is a fire pump powered by an electric motor, and generally consists of a set of fire pumps, electric motors, control cabinets and auxiliary devices. Because the electric motor fire pump set is composed of these parts, it forms a powerful fire protection and power effect, and provides a strong water source support for various fire hydrant systems and sprinkler systems in the building.

In the fire fighting pipeline pump, according to the different installation methods can be divided into vertical fire pumps and horizontal fire pumps, many people have questions about these two common pumps, what is the difference between the two? Shanghai Xizhiquan will explain the difference between horizontal and vertical pumps.

Obviously, different installation methods take up different space. Vertical pipeline pumps are installed vertically, covering a relatively small area, and vertical fire pumps do not require a foundation, while horizontal fire pumps need to be equipped with a base.

According to the different structures of the two pumps, it can be concluded that there is also a certain difference in the ease of maintenance of the two types of fire fighting pipeline pumps. The impeller of the vertical fire pump needs to be dismantled from top to bottom, which makes maintenance more difficult; the horizontal fire pump only needs to have the inlet pipe removed so that the impeller can be overhauled, which is relatively simple.

Due to the different inlet and outlet pipe directions, the pipeline connection between vertical and horizontal is also different. As the vertical pump is a bottom-up structure, while the horizontal fire pump is longitudinally arranged on the base, so the motor of the vertical pump and the pump body are connected in the form of sub-mouth connection, while the horizontal pump needs to use couplings to connect with the motor, and the horizontal pipeline pump needs to be corrected regularly.

Translated with www.DeepL.com/Translator (free version)

All places need to be equipped with fire-fighting facilities, and fire pumps are necessary water intake equipment for fire-fighting facilities. At least one or two fire pumps are equipped. The fire pumps we commonly use are electric fire pumps and diesel engine fire pumps. The difference between the two is The electric fire pump needs to be supplied by the power system. If the power is cut off, the diesel engine fire pump can be started at any time to make up for the original position of the electric fire pump.

The EEJ Fire Pump System is an innovative solution designed to enhance fire safety in various settings. With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression. Its intelligent features, including real-time monitoring and remote control capabilities, contribute to the system’s reliability and ease of operation. Overall, the EEJ Fire Pump System is a reliable choice for safeguarding lives and properties, making it an ideal fire protection solution for commercial buildings, industrial facilities, and residential areas.

EDJ fire pump set is composed of electric pump, diesel pump and stabilized pressure pump. In daily use, as an auxiliary pump, the stabilized pressure pump keeps the existence of liquid (water) in the fire pipeline at all times, and the electric pump works as the main power pump in normal work. When the circuit system is burnt out due to a serious fire, the diesel pump will start instead of the electric pump within ten seconds, which will not be affected by the circuit and complete the fire fighting work. In recent years, EDJ fire pump group has gradually become the first choice of fire protection systems in various office buildings and residential buildings, and its safety

The electric fire pump unit is mainly used for fire hydrant fire extinguishing, automatic sprinkler fire extinguishing and other fire extinguishing systems of industrial and mining enterprises, engineering construction, high-rise buildings and other fixed fire extinguishing systems. It can be used to transport clear water without solid particles and media similar to water in chemical properties. It can also be used in common water supply systems for living and production, as well as construction, municipal water supply and drainage, etc.

Better Technology Group Co., Ltd. is a professional fire pump manufacturer with more than 20 years of industry experience and is deeply loved by domestic and foreign customers.
The diesel engine fire pump has a wide range of lift and flow, which can fully meet the fire water supply in various occasions such as warehouses, docks, airports, petrochemicals, power plants, liquefied gas stations, textiles and other industrial and mining enterprises.

1. Export: All fire pump components should be carefully inspected and packed to ensure that they meet all applicable export laws and regulations. All components should be properly marked or labeled to be easily identified even in a foreign country.

2. Import: The importing country may require certain types of documents to be presented with the fire pumps. These documents may include an export permit, a commercial invoice, a packing list, or perhaps even an insurance policy. If exporting to a foreign country, a customs clearance may also be required.

3. Regulatory Requirements: Fire pump components may fall under certain regulatory requirements, either imposed by the importing country, or by the country of origin. It is important to check with the relevant regulatory authorities to ensure that the equipment meets all applicable regulations.

4. Certification: Depending upon the type of pump being imported, or exported, certain certification may be required. Certification of fire pumps may include UL or ITU ratings, as well as other safety or performance criteria. It is important to comply with all such regulations to ensure the safety of the installed fire pump system.

XBC series diesel engine fire-fighting pump group is a new-style fire-fighting equipment (“equipment” thereafter) developed by this Co. in accordance with GB6245-98 “Performance Requirement and Testing Method of Fire-fighting Pumps” and NFPA20 “Installation of Centrifugal Fire-fighting Pumps” etc. standards and, upon the
fitted fire-fighting pumps (single-stage single-suction type, single-stage double-suction type and sectional multistage type), can be divided into XBC-IS, XBC-S and XBC-D three sub series. The equipment has a wide range of pressure and temperature and can be used for almost every occasion necessary for fire-fighting. The diesel engine fitted with the equipment is an excellent product domestic or imported, features good starting performance, strong overload capacity, compact structure, easy maintenance and use and high degree of automation. The equipment is really a fire-fighting one advanced and reliable in performance. The reasonable use and serious maintenance of the fire pump is the most important prerequisite for ensuring the normal and reliable operation of the pump, giving full play to the emergency function and prolonging the service life. In order to make the pump operator familiar with its structural characteristics, grasp the use and maintenance methods, and make good use of the pump, we have prepared this manual for the operator reference

All accessories of ED small fire-fighting complete water supply equipment are assembled according to the standard (NFPA20). Its configuration depends on the customer’s needs, or the number of pumps and the type of electric and diesel pumps. ED small fire pump sets are usually equipped with two pumps, a main pump (electric centrifugal pump) and a backup pump (diesel centrifugal pump). The choice of electric motor and diesel engine depends on the reliability level of the system.

Discover essential tips for selecting the best fire pump manufacturer, focusing on quality, compliance, and reliability for your fire protection system.

50gpm 6bar ED fire pump set test video

While firefighting pumps are specifically designed for extinguishing fires, they can sometimes be adapted for other applications, such as irrigation or water transfer, depending on the pump type and specifications.

Learn how to choose the ideal fire pump for your building by evaluating system demand, pump type, NFPA 20 compliance, and water supply conditions.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar (40-300 psi)
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set includes diesel engine pumps, electric pumps and jockey pumps.
In various fields, our products find applications in large hotels, hospitals, schools, office buildings, supermarkets, commercial residences, subway stations, train stations, airports, various transportation tunnels, petrochemical plants, thermal power plants,oil storage tanks, large warehouses, industrial and mining enterprises, seawater injection, etc.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar (40-300 psi)
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set includes diesel engine pumps, electric pumps and jockey pumps.

The bought fire fighting outfit has been successfully loaded on the truck moment. It’s composed of delirium liquid position hand, air force air compressor, curvaceous stopcock air compressor and other factors, and the fire water force within 10 twinkles. The device can also be connected in resemblant with signals similar as fire pipings, fire buttons, bank admonitions, temperature and pressure to control fire pump outfit.

This outfit is suitable for hospices, manufactories, storages, domestic diggings, office structures, entertainment places, low- rise structures that are inconvenient to set up high- position water tanks, or hidden systems, temporary structures and other structures that aren’t suitable for high- position water tanks.
The bought fire fighting outfit has been successfully loaded on the truck moment. It’s composed of delirium liquid position hand, air force air compressor, curvaceous stopcock air compressor and other factors, and the fire water force within 10 twinkles. The device can also be connected in resemblant with signals similar as fire pipings, fire buttons, bank admonitions, temperature and pressure to control fire pump outfit.

This outfit is suitable for hospices, manufactories, storages, domestic diggings, office structures, entertainment places, low- rise structures that are inconvenient to set up high- position water tanks, or hidden systems, temporary structures and other structures that aren’t suitable for high- position water tanks.

Diesel engine fire pumps are suitable for use in high lift and high flow fire water supply environments or as backup fire water supply pumps. The reason is that the diesel engine has strong power and can be used with large flow fire deep well pumps, and the diesel engine fire pumps have the characteristics of self-starting when power is off. Emergency water supply is available, so diesel engine fire pumps are favored.

The EEJ Fire Pump System is an innovative solution designed to enhance fire safety in various settings. With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression. Its intelligent features, including real-time monitoring and remote control capabilities, contribute to the system’s reliability and ease of operation. Overall, the EEJ Fire Pump System is a reliable choice for safeguarding lives and properties, making it an ideal fire protection solution for commercial buildings, industrial facilities, and residential areas.

The diesel engine fire pump set has the characteristics of good starting characteristics, strong overload capacity, compact and reasonable structure, convenient maintenance, simple and reliable use, etc. The unit is equipped with protection functions such as overspeed, low oil pressure, three start failures, high water temperature, low oil level, and low battery voltage. At the same time, it can be connected with the customer’s automatic fire alarm device or the fire control system control cabinet produced by our factory to realize the function of remote monitoring.

The company fire pump design in line with the national standard of general packaging, in line with customer needs, standard loading and unloading transportation. Reasonable price, do not cater to customers with ultra-low prices, equal treatment of every customer.

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

Diesel pumps can be combined with electric pumps, jockey pumps, etc. to form an automatic water fire-fighting water supply system, and can be linked with the fire control center.

When the pump set receives the starting command, if the mains power is cut off, the automatic control cabinet of the diesel engine will immediately send a start signal to the starting motor of the pump set to start the motor to start the diesel engine at idle speed, and then gradually adjust the throttle to accelerate the diesel engine to the rated speed . The control system will automatically monitor the operation of the diesel engine, such as the oil pressure, oil temperature, speed of the diesel engine, outlet pressure of the water pump, etc., and determine whether the diesel engine starts normally through automatic monitoring. If the start fails, the control system will send a restart signal, and if the three starts fail, the automatic control system will send a failure alarm. When the pump set receives a signal that the pressure of the pipeline network is restored or the mains power is restored to normal, the pump set will quickly slow down and stop automatically after monitoring the idle position for a period of time.

Explore the outstanding performance and reliability of dual-power emergency fire pump stations. The system is specially designed for harsh environments and uses dual redundancy with diesel and electricity to ensure continuous operation of the firefighting system. It is suitable for critical infrastructure and industrial safety applications.

The biggest difference between a diesel engine fire pump and an electric water pump is that it has its own independent power supply system, which ensures the normal operation of the project without power or power supply. Its role is self-evident, and it can be said to be a great helper in fire emergency .
In terms of industrial applications, diesel engine fire pumps are widely used in emergency water supply for large-scale projects such as high-rise buildings, steel plants, chemical plants, hotels, and water works.

Diesel engine fire pumps are large-scale fire pumps. Diesel engine fire pumps are currently the hottest fire pumps on the market, especially in large warehouses, docks, airports, petrochemicals, power plants, and liquefied gas stations. This kind of fire pump with large flow and high power is often needed.

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions

The ED Dual-Power Fire Pump System combines electric and diesel engine pumps to ensure uninterrupted fire protection and a reliable water supply. In the event of power outages or electrical failures, the diesel engine pump seamlessly takes over, guaranteeing continuous operation of the fire protection system. This dual-power configuration offers both reliability and flexibility, providing comprehensive coverage for fire safety needs. With smart controls and automatic switching mechanisms, the transition between electric and diesel engine pumps is seamless, minimizing system downtime. Equipped with advanced safety features, including monitoring and alarm systems, real-time status updates allow for prompt action in case of any irregularities.
