Efficient and Reliable IS Single-Stage Centrifugal Pumps for Fluid Transfer

XA series single – stage centrifugal pump is one of the most popular pumps in China Better Technology Co., Ltd. launched the single-stage single suction centrifugal pump earlier. This product integrates the advantages of similar products at home and abroad and is designed with excellent hydraulic model. Therefore, the excellent hydraulic performance and structural characteristics of XA series centrifugal pump ensure that users can effectively reduce the operating cost of the pump in various applications.

The pressure stabilizer pump is used in conjunction with the air pressure tank, which is generally a complete set of equipment. Simply speaking, when the water in the air pressure tank decreases (that is, when the user uses it), the gas pressure in the tank decreases. To draw water, it can meet the user’s use pressure and the storage pressure in the tank at the same time. When the storage pressure in the tank reaches the standard, stop the pump and wait for the user to use it.

Smooth operation: The pump shaft and impeller are balanced to ensure smooth operation without vibration.
No water leakage: Carbide seals of different materials ensure no leakage when conveying different media.
Low noise: The water pump supported by two low-noise bearings runs smoothly, except for the faint sound of the motor, which is basically silent.
Low failure rate: The structure is simple and reasonable, and the key parts are equipped with international equipment, and the trouble-free working time of the whole machine is greatly improved.
Easy maintenance: replacement of seals and bearings is simple and convenient.
Less space occupation: The outlet can be left, right and upward, which is convenient for pipeline arrangement and installation and saves space.

The Scope of Work
Water pressure: 0. 2-2.5MPa (20~250 meters);
Flow range: 5-1200L/S
Power: 3kW~2000kW;
Speed range: 1500~3200r/min
Permissible media: Drinking water, chilled water, fire water, and other impurities without abrasive or long-fiber impurities and no chemical or mechanical pump for corrosive media.
Allow the maximum medium temperature 70℃, the maximum ambient temperature of 40℃;
Maximum allowable working pressure of 1.6MPa, the maximum inlet pressure 0.6MPa.
