Features of outdoor box type dual power fire pump

Flow: 30-500GPM
Head: 3-20Bar
Speed: 740-2900r/min
Frequency: 50 HZ or 60 HZ

The ED Dual-Power Fire Pump System combines electric and diesel engine pumps to ensure uninterrupted fire protection and a reliable water supply. In the event of power outages or electrical failures, the diesel engine pump seamlessly takes over, guaranteeing continuous operation of the fire protection system. This dual-power configuration offers both reliability and flexibility, providing comprehensive coverage for fire safety needs.

1.The electric pump is the main fire pump, which can be automatically started according to the fire situation;
2. Equipped with jockey pump;
3.The diesel engine pump is a standby fire pump, and the fire is automatically started without power supply;
4. The diesel engine starts when the electric pump fails;

The product is EJ fire pump set. The EJ fire pump set has one electric pump and one jockey pump. The electric pump in the picture is ISW pump. ISW series horizontal single-stage single-suction centrifugal pump is a new generation of energy saving, environment friendly horizontal centrifugal pump researched and developed by our company, which absorbs advanced technology of similar products abroad and adopts domestic
general performance parameters of centrifugal pumps. In addition, according to different operation temperatures and mediums, we developed the hot-water pump (ISWR), corrosion-resistant chemical pump (ISWH) and oil pump (ISWB).

High-efficiency vertical in-line fire pumps offer stable water pressure, fast start-up, and high durability. They are compact and easy to install, making them suitable for high-rise buildings, factories, and large public facilities, ensuring reliable and safe fire emergency water supply.

The minimum fire rated pressure of ED small fire fighting package set water supply equipment is 3 bar and the minimum fire rated capacity is 25 GPM. ED small fire fighting package set water supply equipment includes at least two power or power source driven pumping units, pressure tanks, pipes, valves and accessories, measurement and control instruments, control cabinets, outdoor rain cover, etc.
Motor: Three-phase asynchronous squirrel-cage motor independently developed and manufactured by our company, which can be controlled in production time and greatly shorten the whole set production time.
Diesel Engine: According to the different parameters of customers, we will choose diesel engines with high cost performance ratio. The main brands are QuanChai, Weichai, ShangChai, FAWDE, Cummins, etc.
Electric Pumps: Electric pumps can use vertical in-line pumps, horizontal end-suction pumps, vertical multi-
stage pumps, horizontal multi-stage pumps, split casing pumps and so on according to the different flow and head of customers.
Diesel Pumps: Diesel pumps can use vertical in-line pumps, horizontal end-suction pumps, vertical multi-
stage pumps, horizontal multi-stage pumps, split casing pumps and so on according to the different flow and head of customers.
Electronic Components: The main electric components is CHNT, if Schneider or other brand electrical are need, should mention it before place the order.
Safety Valve plays a safety protection role in the system. When the system pressure exceeds the prescribed value, the safety valve opens, and a part of the gas/fluid in the system is discharged into the atmosphere/pipeline, so that the system pressure does not exceed the allowable value, so as to ensure that the system does not cause accidents due to excessive pressure.
Pressure Tank: Water is a non-compressible medium. Generally speaking, the pressure drop of fire-fighting pipe network is normal. However, the pressure drop is very slow, the total loss of water in the pipe network isnot large, and the frequent change of pressure in the pipe network leads to frequent start-up and shutdown of pumps. Especially when the power of equipment is high, it will cause great impact on pressure sensors, relaysand motors, thus affecting the performance and life whole equipment. Therefore, it is necessary to choose the right volume of the pressure tank.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar
The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations.

Diesel engine fire pump is a kind of mechatronics equipment that is directly driven by diesel engine fire pump and can start and complete water supply in a short time. Diesel engine pump set is driven by diesel oil without external power supply. Diesel engine pump is suitable for agricultural irrigation, emergency rescue, smelting, hangars, petrochemical oil depots, power plants, liquefied gas stations, textiles and other fire-fighting water supply occasions, especially in the absence of electricity, When the power grid is not satisfied, it is the safest choice to use a diesel engine to drive the water pump.

Electric horizontal multistage pump use for main pump, and standby pump also same, but use diesel engine driven.

The fire pump set is a customized 100gpm EDJ fire pump, which is composed of electric pump + diesel pump + jockey pump. It is a standard fire pump set, which is easy to install the fire pump set on site; easy to debug; Wiring electrical connections; less space requirements; all (pump, drive and controller) on one base, etc.

The electric fire pump set is a fire pump powered by an electric motor, and generally consists of a set of fire pumps, electric motors, control cabinets and auxiliary devices. Because the electric motor fire pump set is composed of these parts, it forms a powerful fire protection and power effect, and provides a strong water source support for various fire hydrant systems and sprinkler systems in the building.

EDJ series fire pump set consists of electric pump + diesel pump + jockey pump and all accessories.
The pressure switch and the control cabinet can automatically turn on/off the three pumps – the electric pump and the pipe charging pump work when there is electricity, and the diesel pump is started when the power is off.
Flow range: 50-5000 GPM
Pressure range: 4-14 bar
Power range: 4-325 KW

Standalone diesel fire pumps are ideal for responding to power outages. They offer strong power output, automated control, energy conservation, environmental protection, and high reliability, ensuring continuous water supply at critical moments. They are widely used in high-rise buildings, industrial plants, and disaster response, providing stable protection for fire safety.

Functions:
Protects fire pump equipment from environmental conditions.
Houses essential components like pumps, controllers, and power sources.
Provides safe and secure access for maintenance personnel.
Design Considerations:
Ventilation & Cooling: Prevent overheating of diesel engines and electric motors.
Drainage System: Prevents flooding in case of pump leakage.
Fire-Resistant Construction: Ensures protection from external hazards.

1. The fire pump pump room should be located close to the water source.

2. The location should allow easy access for maintenance and repair.

3. The area should be well-ventilated and protected from extreme weather conditions.

4. The room should be suitable for operation and maintenance of the fire pump system.

5. The pump room should be protected from unauthorized access.

6. The area should not be subject to flooding.

Now the general diesel engine fire pump set is powered by imported or domestic Cummins, Wuxi Power Engine Factory and other diesel engines produced by large-scale key enterprises in the internal combustion engine industry at home and abroad, through highly elastic couplings or diaphragm couplings produced by professional manufacturers. The engine is directly connected with the water pump, and the power of the diesel engine can reach 880KW. It can be equipped with water pumps of different lifts and flow rates for customers to choose and use according to different needs.

The national standard name of the diesel engine fire pump is “engineering diesel engine fire pump set”, and the national standard model is XBC-QYW/XBC-QYS where L is the lift value and Q is the flow value. XBC diesel engine fire pump set is the latest according to the national standard GB6245-2006 “fire pump performance requirements and test methods”. This series of products has a wide range of lift and flow, and can fully meet the fire water supply in various occasions such as warehouses, docks, airports, petrochemicals, power plants, liquefied gas stations, textiles and other industrial and mining enterprises.

dvantages：
Integrated fire pump systems combine pumps, power, and controls into one unit, offering:
1.Easy Installation – Pre-assembled, requiring only pipe and power connections.
2.Space-Saving – Compact design for limited-space rooms.
3.Efficient & Reliable – Optimized performance with reduced failure rates.
4.Smart Control – Remote monitoring and auto start-stop.
5.Emergency Backup – Supports electric or diesel power for uninterrupted operation.
Applications：
Ideal for high-rise buildings, industrial parks, warehouses, hospitals, and airports, providing reliable fire protection for various facilities.

Standard:
       UL    Flow：100-3000 GPM    Head： 90-250 PSI
       NON-UL   Flow：100-10000GPM   Head： 40-250 PSI

Electric fire pump: It is an important part of the fire water supply system. Divided into ordinary type and foam type. The ordinary type is used for general fire water supply; the foam type is equipped with an adjustable proportion mixer and a cam pump, which can deliver the mixed liquid to various foam launching devices to extinguish various oil fires. The electric fire pump consists of two parts, the motor and the pump. The pump and the motor are coaxial. The pump structure includes pump body, rotor, pump cover, mechanical seal and other components.

It’s a customized EJ fire pump set consisting of electric pump, jockey pump along with control panel, and accessories. It is equipped with priming tank for doing negative suction.

The fire pump is a high-tech product, which is characterized by high efficiency, fast pumping speed, very strong sealing, and low leakage, which can also be said to be no leakage. The use of fire pumps is very extensive, of course, the most important one is used in the fire protection industry, it is also used in water treatment, environmental protection industry and so on. Among these uses, the fire protection industry uses the most. The fire protection industry makes full use of the advantages of fire pumps, which is the advantage of fast pumping. Because most of the work in the fire protection industry is to extinguish fires, the fire pump plays a very important role. Fire pumps are not just used in the firefighting industry. Fire pumps are also used in many other places. In larger industries, such as industry, as well as urban water supply and drainage, and water transportation for the construction of high-rise buildings, there is also water delivery over relatively long distances. There are also smaller industries, such as heating and boilers.

Fire pump system is made of Electric+Diesel+Jockey pump
Operation: 1 Duty (electric) + 1 standby (diesel engine) + 1 Jockey
Capacity: 100, 150, 200, 300, 400, 500, 750, 1000…GPM with pressure 4, 5, 6, 8, 10… Bar.
Pressure vessel 25, 50, 75, 100…liters, pressure will be 0.6mpa, 1.0mpa, 1.6mpa, select according to pump head.

1. Fire Pump: A fire pump is the heart of a fire sprinkler system and is used to create the necessary water pressure to make the system work. It is powered by an electric motor or diesel engine and pumps water from a water source to the sprinkler system.

2. Control Panel: The control panel is the brains of the fire sprinkler system. It controls the flow of power to the pump and monitors the sprinkler system for any changes in pressure or water flow. It also triggers alarms and other safety devices in the event of a fire.

3. Suction Pipe: The suction pipe is connected to the fire pump and draws water from the water source. It is usually made of steel and must be strong enough to withstand the pressure exerted by the pump.

4. Pressure Gauge: The pressure gauge is used to measure the pressure in the system and ensure that the pump is providing the correct amount of water pressure. It is usually mounted on the control panel.

5. Valves: Valves are used to control the flow of water to and from the system. They are typically operated manually or automatically and can be used to start and stop the pump, control the flow of water, and isolate parts of the system for maintenance.

The diesel engine fire pump is usually used as a backup facility, so it will only start automatically when the fire signal comes, and when the electric water pump fails or the power supply is cut off. When it has a device for starting the pump at ultra-low pressure, its matching electric water pump control cabinet should also have a device for starting the pump at ultra-low pressure, and the lower limit of the two pumps should have a certain pressure difference.

The EJ (Electric pump + Jockey pump) Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

Fire pump system is made of Diesel+Jockey pump
1. Diesel engine pump, can use single stage pump, horizontal split case pump, end suction pump, multistage pump, material can be cast iron, stainless steel, and bronze impeller , with fuel tank, water tank，fan, control box
2. Jockey pump, horizontal or vertical, capacity will be small, but head should be higher than electric and diesel engine pump
Jockey material casing: cast iron, shaft and impeller: SS304

Setting up the fire pump control system correctly is crucial to ensure the pump operates efficiently and reliably during emergencies. Here are the general steps to set up the fire pump control

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations.

The EDJ fire pump set equipment produced by Better Technology Group Co., Ltd. is composed of electric fire pump and diesel fire pump. It is designed and manufactured according to the fifth part of GB 27898.5-2011 fixed fire water supply equipment <>, in line with the new 3CF Require certification and obtain 3CF certification for fire protection products.

The fire-fighting dual-power water supply equipment is suitable for all kinds of emergency backup pumps. When the mains is normal, the electric pump set is put into work. When the power supply fails and the electric fire pump cannot be put into use normally, the diesel engine fire pump set can be automatically put into operation to ensure firefighting. Fire extinguishing is carried out normally, and the diesel engine fire pump set is equipped with various automatic functions to meet the requirements of national standards, ensuring that the equipment is in a normal standby state for a long time, and can be put into fire fighting work at any time.
