Fuel Tank for Enhanced Safety

ISG series vertical single-stage single-suction centrifugal pump is a new generation of energy-saving and environmentally friendly vertical centrifugal pump developed by the company’s technical staff on the basis of absorbing the advanced technology of similar products at home and abroad, and using the performance parameters of domestic general centrifugal pumps. This series of pumps has excellent performance, high reliability, long life, reasonable structure and beautiful appearance, and has a leading level in the industry.

1. The pump is a vertical structure, the inlet and outlet diameters are the same, and they are located on the same center line. It can be installed in the pipeline like a valve. The appearance is compact and beautiful, the floor space is small, and the construction investment is low. Can be used outdoors.
2. The impeller is directly installed on the elongated shaft of the motor, the axial dimension is short, the structure is compact, and the pump and motor bearings are reasonably arranged, which can effectively balance the radial and axial loads generated by the operation of the pump, thereby ensuring the smooth operation of the pump. Low vibration and low noise.
3. The shaft seal adopts mechanical seal or mechanical seal combination, adopts imported titanium alloy sealing ring, medium-sized high temperature resistant mechanical seal and hard alloy material, wear-resistant seal, which can effectively prolong the service life of mechanical seal.
4. Easy installation and maintenance, no need to dismantle the pipeline system, just remove the pump joint seat nut to extract all the rotor parts.
5. The series and parallel operation modes of pumps can be adopted according to the requirements of use, that is, the needs of flow and head.
6. The vertical and horizontal installation of the pump can be adopted according to the requirements of the pipeline arrangement.

The non-negative pressure variable frequency water supply equipment takes the municipal pipe network as the water source, and makes full use of the original pressure of the municipal pipe network to form a closed continuous relay pressurized water supply mode, with good energy saving effect and no secondary pollution of water quality. Development and extension of water supply equipment.

The fire control cabinet is widely used in many high-rise buildings, shopping malls, schools and other crowded places. This equipment enables the fire pump to cut off the circuit or alarm through the components in the fire control cabinet when it fails, and play a warning and The role of protection.

1. Industrial and urban water supply and drainage, high-rise building pressurized water supply, garden sprinkler irrigation, fire pressurization, long-distance transportation, HVAC refrigeration cycle, long-distance transportation, cooling tower water supply, garden sprinkler irrigation, refrigeration flushing, bathroom and other cold and warm water circulation increase Pressure and equipment matching
2. Food, pharmacy, brewing, metallurgy, chemical industry, textile, wood processing, papermaking, high temperature hot water pressurized circulation transportation of boilers in restaurants, bathrooms, hotels, etc. and urban housing heating circulation pumps
3. Petroleum, chemical, metallurgical, electric power, paper, food, pharmaceutical and synthetic fiber sectors
4. Petroleum products such as gasoline, kerosene, diesel
5. Power station water supply and drainage, farmland drainage and irrigation and various water conservancy projects.
6. Pump rooms for key projects, central air-conditioning and scientific research institutions, hospitals, etc.

While the initial investment in firefighting pumps and fire protection infrastructure may represent a significant capital expenditure, the long-term benefits of enhanced fire safety, reduced property damage, and potential savings in insurance premiums outweigh the costs. Cost-benefit analyses and risk assessments help stakeholders make informed decisions about allocating resources to improve fire protection capabilities and mitigate financial risks associated with fire emergencies.

The waste cone is providing quick visual confirmation of proper water flow in the fire pump system.

The most advanced externally mounted PTFE bellows mechanical seal is adopted, which has multi-layer protection and prolongs the service life of the mechanical seal. When conveying the medium containing impurity particles, it can be equipped with single-end hard-to-hard (silicon carbide to silicon carbide) without cooling water. ) mechanical seal, so users need to consider the solid content in the medium when selecting models.

Fuel tank specifications：200L/400L/600L/800L/1000L/1200L/1500L/1800L/2100L/2500L/3100L/3600L/4100L/4500L
The diesel fire pump system serves as a backup power solution, utilizing a diesel engine to provide power and ensure the fire pump’s reliable operation during electrical outages. The associated fuel tank is a crucial component for storing diesel fuel and providing a continuous supply to the diesel engine, ensuring a sustained water flow during fire incidents.

The multistage pump is a centrifugal pump in and out of the water section and the middle section, through the rod combination together, its output water pressure can be very large, but also depends on the rotation of the impeller to obtain the centrifugal force, so that the material. When the gas density reaches the working range of the mechanical vacuum pump, it is extracted, and the high vacuum is gradually obtained.

The Fire Pressure Stabilization Equipment, coupled with the CDL Vertical Multistage Fire Pump, offers a comprehensive solution to elevate fire safety measures. This powerful combination ensures a consistent water pressure for effective fire suppression. By incorporating pressure stabilization technology, this system guarantees an uninterrupted fire water supply, efficient water distribution, and reliable operation of fire hydrants and sprinkler systems. With advanced infrastructure and the ability to maximize firefighting capabilities, this configuration significantly enhances overall fire safety standards. Investing in fire pressure stabilization equipment is a proactive step towards ensuring superior fire protection and providing peace of mind in critical situations.

It is composed of pressure water tank, control cabinet, top pressure gas storage system, decompression release device and other basic components; In the condition of fire fighting, the compressed gas is filled into the pressure water tank to replace the fire fighting water in the tank, and always maintain the rated working pressure of fire fighting, and the fixed fire water supply equipment for the fire fighting pipe network.

used for pumping normal temperature water and warm water under 100°C from wells, river, lake , sea. Type JCW are better used for city, factory dirty water and water containing great sand in river and sea, widely used in factories and mines, city and countries, petrolatum filed, plant and irrigation on farmland.

Our highly acclaimed Box-type Non-Negative Pressure Water Supply Equipment is the savior for your hotels, hospitals, schools, and more! Not only does it provide stable water flow and pressure, but it also guarantees fresh water quality! Suitable for life water supply systems in high-rise buildings, residential communities, and large-scale architectural complexes, bid farewell to water shortage worries! The Box-type Non-Negative Pressure Water Supply Equipment features an advanced automatic control system that instantly starts the water pump when demand increases, providing you with a continuous and stable water flow. And when demand decreases, the pump intelligently stops, avoiding energy waste! The compact box-type structure makes installation and maintenance a breeze! Whether it’s solving water supply issues in low-pressure areas or addressing the needs of places like hotels, hospitals, and schools where water cannot be shut off but face insufficient tap water pressure, our Box-type Non-Negative Pressure Water Supply Equipment offers the perfect solution!

The double-blade impeller structure is adopted, which greatly improves the passing capacity of dirt.
The mechanical seal adopts a new type of grinding pair, and runs in the oil chamber for a long time;
The overall structure is compact, the volume is small, the noise is low, the energy saving effect is remarkable, the maintenance is convenient, and the user is convenient to replace;
Can be used within the design range without overloading the motor;

The pressure tank, also known as the pressure tank, is one of the important components in the secondary water supply equipment. Its core function is to stabilize the water pressure, so it is called the pressure tank.
The reason why the surge tank can stabilize the water pressure is mainly achieved by compressing the gas in the capsule, because water is an incompressible fluid, and water with the same pressure can compress the gas to store water and have a certain pressure.

Centrifugal pump is designed according to the principle of centrifugal force. The high-speed rotating impeller blade drives the water to rotate and the water is thrown out, so as to achieve the purpose of transportation

XA bare pump with below Models for packing
XA100/26
XA80/26
XA65/32
XA50/32

Export fire pump set will be packaged with free fumigating wooden case.

The diesel engine with right-angle gearbox combination is a high-performance power transmission solution widely used in various industrial applications. It features a diesel engine as the primary power source and a right-angle gearbox for efficient power redirection and speed matching. This compact and reliable duo enhances production efficiency, reduces energy consumption, and provides a stable power source for industrial automation and ship propulsion systems. Its adaptability to diverse climate conditions and load demands further reinforces its significance in modern industries.

The horizontal pipeline centrifugal pump is a new generation of energy-saving and environmentally friendly horizontal centrifugal pump developed by itself on the basis of absorbing the advanced technology of similar products at home and abroad. The pump has excellent performance, high reliability, long life, reasonable structure and beautiful appearance, and has the leading level in the industry.

The Fire Pressure Stabilization Equipment, coupled with the CDL Vertical Multistage Fire Pump, offers a comprehensive solution to elevate fire safety measures. This powerful combination ensures a consistent water pressure for effective fire suppression. By incorporating pressure stabilization technology, this system guarantees an uninterrupted fire water supply, efficient water distribution, and reliable operation of fire hydrants and sprinkler systems. With advanced infrastructure and the ability to maximize firefighting capabilities, this configuration significantly enhances overall fire safety standards. Investing in fire pressure stabilization equipment is a proactive step towards ensuring superior fire protection and providing peace of mind in critical situations.

Regular maintenance includes checking the foam concentrate levels, inspecting and testing the proportioning system, cleaning the components, and ensuring that all seals and connections are intact.

1.Enterprise unit waste water discharge.
2.Urban sewage treatment plant discharge system.
3.Hospital, hotel, high-rise building sewage discharge.

The equipment from Better Technology Group is debugging now

Integrated Prefabricated Pump Station

The pump station is supplied as an integrated unit. It includes a pump station cylinder, pressure pipeline, maintenance platform, maintenance ladder, grill filter, coupling system, pump lifting system, ventilation, anti-skid manhole cover, lighting system, etc.

According to CFO fluid dynamics finite element analysis, the base structure is optimized to prevent sludge deposition in sewage treatment and no odor residue.

All internal installation and commissioning work is completed in the factory. The pump station is only installed on the site, which greatly reduces the civil construction period and engineering cost, and reduces the overall investment of the owner.

The pumping station cylinder is made of FRP, and the internal fittings are made of anti-corrosion materials such as SUS304 and hot-dip galvanizing. No maintenance is required, and the normal service life can reach more than seven years.

Intelligent operating system, easy to understand, to run, monitoring without personnel supervision

Welcome your inquiry!

Oil-water separation device is a device that separates oil and water. The oil-water separation device is one of the important environmental protection facilities in the sewage treatment plant. Its function is to improve the biodegradability of sewage and reduce the energy consumption and treatment cost of sewage treatment.

The electrical control cabinet of fire pump set mainly has the functions of starting and stopping the pump, switching between main and standby pumps, manual and automatic switching, dual power switching, patrol inspection, protection, and feedback for mechanical emergency start.

The fire control cabinet is a control cabinet that controls the operation of the fire pump. The fire control cabinet is a collection of many electrical components. These electronic components have different functions. They cooperate with each other to effectively control the operation of the fire pump. In addition to the function of controlling the operation of the fire pump, the fire control cabinet also has functions such as overload protection, overvoltage protection, overcurrent protection, phase loss protection, short circuit protection, and overheat protection that a single fire pump cannot possess.

Hygienic and clean to use, high efficiency, low noise, mild corrosion resistance and compact structure, beautiful appearance, small size, light weight, convenient use and maintenance, reliable sealing performance
