Single stage double suction centrifugal pump

The end suction pump works by rotating the impeller to make the water centrifugally move. Before starting the centrifugal pump, it is necessary to fill the pump casing and the suction pipe with water, and then start the motor to make the pump shaft drive the impeller and the water to rotate at a high speed. It flows into the pressurized water pipeline of the single-suction pump. According to the material type and the different configurations of the sealing system and cooling system, the single-stage single-suction pump has a wide range of applications. The end suction pump can pump clear water media, and can be used in air conditioning, heating, pressurization, building water supply, fire protection buildings, etc. It can pump chemical media similar to water and other corrosive liquid media, and can be used in chemical, horizontal, pharmaceutical, metallurgy, petroleum and other fields.

ISO end-suction pumps offer high efficiency, high flow capacities, and the ability to withstand high pressures. The suction inlet is designed to efficiently intake fluids, while the pump itself is constructed to be compact, making it suitable for installation and maintenance in limited spaces.They also provide multiple material options to accommodate different fluid mediums, including corrosive and high-temperature substances. ISO end-suction pumps find wide application in industries such as chemical, petroleum, pharmaceutical, food and beverage, and water treatment, where they are used for fluid transportation, circulation systems, heating, and cooling systems, among others. In conclusion, ISO end-suction pumps are reliable and efficient industrial pumps that meet global standards, making them suitable for various industries and applications.

The XBD-L Vertical Single stage single suction fire pump is specifically designed for fixed fire protection systems in a wide range of settings, including businesses, construction projects, and high-rise buildings. It is a vital component in fire hydrant extinguishing systems, automatic sprinkler fire suppression systems, and more. This pump set is capable of delivering clear water and water-like media with physical and chemical properties similar to water, without solid particles, at temperatures below 100°C. It is also suitable for fire protection, domestic water supply, shared water supply systems, as well as building and municipal water supply and drainage applications.

Electric fire pumps are a crucial component of a building’s fire safety strategy. They ensure that the fire protection system has adequate water pressure to combat fires effectively, providing a critical defense that can protect lives and property. Their reliability and performance can significantly impact the effectiveness of firefighting efforts during an emergency.

Vertical turbine electric pump are better used for city, factory dirty water and water containing great sand in river and sea, widely used in factories and mines, city and countries, petrolatum filed, plant and irrigation on farmland.

Site conditions
YE3 series motors air suitable for almost all applications and operate satisfactorily at temperatures from -20 to +40 and
altitudes up to 1000 meters above sea level.
Temperature and insulation
The Motors’ insulation system are designed by Class F(155 ), operated with Class B(80K). Which incerase the motor useful
life and reliability.
Cooling and ventilation
The standard cooling method is totally Enclosed Fan Cooled(TEFC) in accordance with IC411 of IEC60034-6. Standard
motors are equipped with radialflow plastic fans.
Protection class
The standard degrees of protection is IP55.The IP55 enclosure means complete hoseproof and dustproof protection. A
higher degrees of protection is available.
Motor protection
Motors can be installed with PTC, PT100, such as winding and bearing temperature measurement as well as other kinds of
protection on request

The Horizontal Multistage Pump is an exceptional engineering solution that offers high performance and reliability for fluid handling applications. With its unique multistage impeller design, it delivers efficient and incremental pressure boosting for high-pressure and high-flow scenarios. Whether used in water supply systems, industrial processes, irrigation, or building cooling, this pump ensures stable water pressure and flow. Its compact design allows for easy installation and maintenance, while its superior construction materials guarantee durability and long-term reliable operation. Choose the Horizontal Multistage Pump to achieve exceptional performance and success in your fluid handling projects.

The Portable Irrigation Pump is a portable and user-friendly tool used primarily by farmers and gardening enthusiasts for small-scale irrigation in fields, vegetable gardens, and flower beds. With its manual operation, this pump requires no external power source, making it suitable for remote areas lacking electricity or other energy supplies.

Vertical fire pumps are mainly used in engineering construction enterprises and institutions. The system includes fixed fire extinguishing systems, high-rise building indoor fire hydrant fire extinguishing systems, and automatic sprinkler fire extinguishing systems. It does not contain solid particles and water with similar physical and chemical properties. Based on the water medium, the public water supply system can be used for fire protection, life, production, construction, etc.

Flow：50-7500 GPM
Head：3-20 Bar 40-300 psi
Power：11-1000 kw
Caliber：50-400 mm
Frequency：50 or 60 Hz

Stainless steel deep well pump with rust, no pollution, long life, energy saving and other characteristics, the product of high head, general deep well pump longer, higher head.

This series of pumps adopts a vertical structure, which can better save the floor space, has the characteristics of high efficiency, wide application range, flexible installation forms and convenient maintenance.

A split pump is a centrifugal pump with two single-suction impellers or a double-suction impeller supported between bearings. The housing is axially separated from opposing suction and discharge flanges. This facilitates maintenance of the pump. This robust and simple design is especially suitable for high flow applications.

Vertical turbine pumps, electric motor fire pumps, diesel engine fire pumps and submersible deep well pumps can all use mechanical seals, and mechanical seals with different materials and performances can be selected according to different environments. In pumps with different frequency of use, mechanical seals should be inspected and maintained according to actual conditions to ensure their long-term stability.

CDL series vertical stainless steel multistage centrifugal pump is anon-self-PRIming vertical MULTIstage centrifugal PUMP DESIGNED and MANUFACTURED by absorbing domestic and foreign technology, using standard vertical motor and quick loading mechanical seal, easy to replace.

The over-current part of the pump is made of stainless steel (304\316) material, which can be applied to mildly corrosive media. This product can replace foreign CR, CRN and other similar products. After the product is put on the market, with its energy-saving, good quality, wide range of use and other characteristics, by the majority of users love.

Selecting the right fire pump is a critical decision that depends on a range of factors. These factors include the facility’s water supply source, the building’s size and layout, the required flow rate, and the local fire codes and regulations.

For example, a large industrial facility may require a high-capacity fire pump, while a small office building may need a lower-capacity pump. The choice also depends on whether the facility uses municipal water, a private water supply, or a combination of both.

Consulting with a fire protection engineer or specialist is often recommended to ensure the selection of the most suitable fire pump for a specific application.

ISG vertical single-stage single-suction centrifugal pump
1.Suction pressure≤1.0Mpa, or maximum operation pressure
of pump system≤1.6Mpa, that is, pressure in suction nozzle+pump
lift≤1.6Mpa. If operation pressure of pump system is higher than
1.6Mpa, it should be indicated in order, so that we can use more
reasonable material for flow and connecting parts in pump.
2. Ambient temperature＜40℃ ＜ , relative humidity 95%.
3. In the conveyed medium, solid particles should be less than
0.1% in unit volume, and granularity＜0.2mm.

ISO series centrifugal pump is a single-stage single-suction centrifugal pump developed by China Better Technology Co., Ltd. with reference to international similar products using modern fluid mechanics to meet the international standard ISO9908 secondary energy efficiency standard.
This product combines the strengths of similar products in China and abroad and is designed with excellent hydraulic models, therefore, its excellent hydraulic performance and structural features ensure that the user can effectively reduce the operating cost of the pump in various applications.

Flow：50-5000 GPM
Head：30-160 m 3-16 Bar 40-232 psi
Power：11-1000 kw
Frequency：50 or 60 Hz

The XBD-L Vertical Single stage single suction fire pump is specifically designed for fixed fire protection systems in a wide range of settings, including businesses, construction projects, and high-rise buildings. It is a vital component in fire hydrant extinguishing systems, automatic sprinkler fire suppression systems, and more. This pump set is capable of delivering clear water and water-like media with physical and chemical properties similar to water, without solid particles, at temperatures below 100°C. It is also suitable for fire protection, domestic water supply, shared water supply systems, as well as building and municipal water supply and drainage applications.

Packaging & Delivery
Packaging details: standard export wood case packing or as required
Delivery detail: within 30 days
Specifications
1.Fire Water
2.Fire sprinkler system water supply
3. Industrial process water recycling
4. Long operation life
Application
1. Fire sprinkler system water supply, high-rise building partitions, fire water supply.
High-rise buildings and residential group domestic water supply system.
2. The district water supply and water transportation, industrial process water recycling, cleaning systems, high pressure washing systems.

The XBD-DL vertical multistage fire pump is a top-tier technology designed to enhance the safety and efficiency of building fire protection systems. With advanced design and technology, this pump offers excellent corrosion resistance and durability, making it suitable for various environmental conditions. Its high-performance turbine blade design and efficient motor ensure powerful water pressure and flow, enabling rapid and effective water delivery. The intelligent monitoring system and fault alarm function enhance the pump’s reliability and availability. By choosing the XBD-DL vertical multistage fire pump, you gain an innovative and efficient solution to enhance the safety and efficiency of your fire protection system.

The Scope of Work
Water pressure: 0. 2-2.5MPa (20~250 meters);
Flow range: 5-1200L/S
Power: 3kW~2000kW;
Speed range: 1500~3200r/min
Permissible media: Drinking water, chilled water, fire water, and other impurities without abrasive or long-fiber impurities and no chemical or mechanical pump for corrosive media.
Allow the maximum medium temperature 70℃, the maximum ambient temperature of 40℃;
Maximum allowable working pressure of 1.6MPa, the maximum inlet pressure 0.6MPa.

·UL Standard:
Flow:50-500GPM
Head:6-16 Bar（90-230PSI）
·Non-UL Standard:
Flow：50-5000 GPM
Head：3-16 Bar（40-232 psi）

ISO end-suction pumps offer high efficiency, high flow capacities, and the ability to withstand high pressures. The suction inlet is designed to efficiently intake fluids, while the pump itself is constructed to be compact, making it suitable for installation and maintenance in limited spaces.They also provide multiple material options to accommodate different fluid mediums, including corrosive and high-temperature substances. ISO end-suction pumps find wide application in industries such as chemical, petroleum, pharmaceutical, food and beverage, and water treatment, where they are used for fluid transportation, circulation systems, heating, and cooling systems, among others.

The air conditioning circulation pump, also known as a chilled water pump, is a vital component of air conditioning systems used for circulating refrigerant or chilled water. It plays a crucial role in heat exchange and temperature regulation. The pump consists of an electric motor, pump body, impeller, sealing device, and control system. It enables the circulation of the refrigerant or chilled water to absorb or release heat, thereby achieving the desired cooling effect and regulating indoor temperatures. Key features of air conditioning pumps include high efficiency, control and automation capabilities, and diverse options to suit different system requirements. The selection of an appropriate air conditioning pump should consider specific system needs, flow rates, head pressures, and mediums. Consulting with professionals and adhering to maintenance guidelines ensures the safe and reliable operation of the pump within air conditioning systems.

Flow:25≤Q≤5000GPM
Head:50＜H≤300m
Speed:1500-3550 rpm
Frequency:50 Hz or 60 Hz

Flow: 1~300L/s
Head: 0.15~1.6MPa
Speed: 960~3500r/min

– Jockey pumps in large-scale facilities:

Pressure Maintenance: Keep the fire protection system pressurized to prevent false alarms and ensure immediate response during a fire event.
Leak Compensation: Compensate for minor leaks in the system, maintaining steady pressure without activating the main fire pump.
System Readiness: Ensure the system is always ready for immediate use by maintaining constant pressure levels.

The XA single-stage centrifugal pump is a widely used industrial pump designed for fluid transportation and handling in various industries. It features a simple and compact design with a rotating impeller and a stationary pump casing. The pump offers high efficiency, reliability, and flexibility in installation. It finds applications in water treatment, agriculture, construction, petrochemicals, energy, pharmaceuticals, and food processing. The XA pump is capable of handling different fluid mediums and provides efficient flow control. Its operating principle utilizes centrifugal force to draw in and propel fluids through the pump. Overall, the XA single-stage centrifugal pump is a reliable and efficient solution for fluid pumping needs in industrial settings.
