The role of vertical multistage centrifugal pump set

The diesel engine fire pump has automatic, manual and fault self-checking functions. It can monitor the working state of the whole process, restore the function of failure start, automatic pre-lubrication and automatic restart of preheating, so that the equipment start-up is safer and more reliable. It has the functions of central control room remote control, remote control and field bus connection. The battery is fully automatic floating charge (constant current, constant voltage, trickle charge) mode to ensure that the battery is in a standby state at any time. Diesel engine fire pump is easy to use, equipped with remote instrument and instrument, which can be connected to the control center as needed, easy to install and use, and easy to maintain.

EDJ series fire pump set consists of electric pump + diesel pump + jockey pump and all accessories.
The pressure switch and the control cabinet can automatically turn on/off the three pumps, the electric pump and the pipeline pressure pump work when there is electricity, and the diesel pump is started when the power is off.
Flow range: 50-5000 GPM
Pressure range: 4-14 bar
Power range: 4-325 KW

1.Flow: 50-5000GPM
2.Head: 3-20Bar
3.Caliber: 25-800mm
4.Power: Electric pump: 1.5-710 kw, Jockey pump: 0.55-160kw
5.Speed: 740-2900r/min
6.Material: HT200，SS304，Bronze
The EEJ Fire Pump System is an innovative solution designed to enhance fire safety in various settings. With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression.Overall, the EEJ Fire Pump System is a reliable choice for safeguarding lives and properties, making it an ideal fire protection solution for commercial buildings, industrial facilities, and residential areas.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The outdoor fire pump set is designed to enhance fire safety in various applications. From powering fire hydrants and stabilizing sprinkler systems to safeguarding residential areas, industrial buildings, and high-risk environments, the Outdoor Fire Pump Set delivers optimal performance and unmatched reliability. Elevate your fire safety standards with this powerful solution and gain peace of mind knowing that your property and lives are protected. Choose the Outdoor Fire Pump Set and experience the ultimate fire protection solution.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

Jockey pumps help extend the lifespan of fire pumps by maintaining system pressure and preventing unnecessary cycling of the main fire pump. By handling minor pressure fluctuations and small leaks, jockey pumps reduce the wear and tear on fire pumps, which would otherwise start and stop frequently to maintain pressure. This reduced cycling minimizes mechanical stress on the fire pump’s components, such as bearings, seals, and impellers, thereby prolonging its operational life. Additionally, jockey pumps consume less power and operate more quietly than fire pumps, leading to energy savings and reduced noise pollution in facilities. By ensuring that fire pumps only operate during actual emergencies, jockey pumps contribute to the long-term reliability and efficiency of the fire protection system.

Operation of Electric Fire Pump Before start: 1. Turning the clutch by hand, there should be no jammed phenomenon at the turner position. 2. Opening the inlet valve and the vent valve, letting the water fill into the pump’s chamber, then closing the vent valve. 3. Clicking the switch of motor, and confirming whether the turning is right ornot. Running: 1. Fully opening the inlet valves, and closing the valves of the outlet pipe. 2. Connecting the power, Opening the valves of the outlet pipe and adjusting the needed working point when the turning velocity is normal. 3. Watching whether there exist abnormalities or not, if yes, should the pump be stopped and inspected before re-running. Stop: 1. After turning off the outlet valves one by one, shutting off the power. 2. Shutting off the inlet valves. 3. If the ambient temperature is below 0℃, some warm-keeping measures should be adopted.

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar 40-300 psi
The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

Diesel and electric fire pumps are the two primary types of fire pumps used in fire protection systems, each with its own advantages and considerations. Diesel fire pumps are powered by internal combustion engines and are typically used in locations where a reliable electric power supply is not available or where redundancy is needed to ensure continuous operation during a power outage. Diesel pumps are known for their reliability and ability to operate independently of the electric grid, but they require regular maintenance of the engine and fuel system, including fuel storage and periodic testing.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

Flow: 30-500GPM
Head: 3-20Bar
Speed: 740-2900r/min
Frequency: 50 HZ or 60 HZ

The ED Dual-Power Fire Pump System combines electric and diesel engine pumps to ensure uninterrupted fire protection and a reliable water supply. In the event of power outages or electrical failures, the diesel engine pump seamlessly takes over, guaranteeing continuous operation of the fire protection system. This dual-power configuration offers both reliability and flexibility, providing comprehensive coverage for fire safety needs.

Fire pumps are designed to adapt to varying water supply conditions, such as fluctuating pressures or varying water levels in a reservoir. They achieve this through features like variable speed drives, which adjust the pump’s speed to maintain consistent water pressure and flow, regardless of changes in the supply.

These pumps ensure that a building’s fire protection system operates effectively during an emergency, providing the necessary water pressure and flow to control or extinguish fires, thereby protecting lives and property.

Flow: 30-9000 GPM
Head: 3-20Bar
Speed: 740-2900r/min
Material: HT200, SS304, Bronze

The EJ Fire Pump Set is combined an electric pump and a jockey pump.In various fields, our products find applications in large hotels, hospitals, schools, office buildings, supermarkets, commercial residences, subway stations, train stations, airports, various transportation tunnels, petrochemical plants, thermal power plants,oil storage tanks, large warehouses, industrial and mining enterprises, seawater injection, etc.

Application Scope
Equipment for warehouses, docks, airports, petrochemical, power plants, liquefied gas, textiles, ships, oil tankers and other occasions of a fire service.

Using Instruction
Altitude ≤ 1000m;
Ambient temperature: +5 °C ~ +40 °C;
Relative humidity: <= 90%.

Diesel engine fire pump is also called “engineering diesel engine fire pump group”. Diesel engine fire pump group has the characteristics of good starting characteristics, strong overload capacity, compact and reasonable structure, convenient maintenance, simple and reliable use and so on. The unit is equipped with protection functions such as overspeed, low oil pressure, failure to start three times, high water temperature, low oil level, and low battery voltage. It can fully meet the fire water supply in various occasions such as warehouses, docks, airports, petrochemicals, power plants, liquefied gas stations, textiles and other industrial and mining enterprises.

The Fire Pressure Stabilization Equipment, coupled with the CDL Vertical Multistage Fire Pump, offers a comprehensive solution to elevate fire safety measures. This powerful combination ensures a consistent water pressure for effective fire suppression. By incorporating pressure stabilization technology, this system guarantees an uninterrupted fire water supply, efficient water distribution, and reliable operation of fire hydrants and sprinkler systems. With advanced infrastructure and the ability to maximize firefighting capabilities, this configuration significantly enhances overall fire safety standards. Investing in fire pressure stabilization equipment is a proactive step towards ensuring superior fire protection and providing peace of mind in critical situations.

Facilities can ensure the readiness and operational readiness of diesel fire pumps by implementing a comprehensive maintenance program, conducting regular testing and inspections, and providing ongoing training for personnel responsible for operating and maintaining the pumps. This may include performing weekly or monthly visual inspections, conducting quarterly or annual performance tests, and scheduling preventive maintenance tasks based on the manufacturer’s recommendations and industry best practices. Additionally, facilities should maintain accurate records of all maintenance activities and testing results to demonstrate compliance with regulatory requirements and ensure accountability.

The small EJ fire pump set is suitable for low buildings. The fire pump set consists of an ISW electric pump and a CDL jockey pump. The ISW pump is easy to install and maintain, no need to disassemble or move the piping system, just lift the pump to connect the flat nut to take out all the rotors part. The impeller is directly mounted on the main shaft of the motor, with a short axial dimension and a compact structure, which can calibrate the rounding of the pump to effectively generate radial and axial loads, thereby ensuring smooth operation, vibration and low noise of the pump.

The multi-stage fire pump consists of two parts: the motor and the pump, and the motor and the pump are coaxial. The structure of the pump consists of pump body, impeller, pump cover, mechanical seal and so on. The inlet and outlet of the pump are on the same horizontal axis and have the same caliber specification, so the loading and unloading is very convenient, and the floor space is small. The pump is fitted with a base for easy installation and increased pump stability. It is used to transport clear water without solid particles, liquids with physical and chemical properties similar to water. It is mainly used for pressurized water delivery in fire protection system pipelines, and is also suitable for industrial and urban water supply and drainage.

Regular training for personnel on the operation and maintenance of fire pumps is crucial for ensuring the reliability and effectiveness of a fire protection system. Training helps personnel understand the system’s components, recognize signs of potential issues, and perform routine maintenance tasks, such as inspecting for leaks, testing alarms, and checking pump alignment. Familiarity with emergency procedures and the ability to respond quickly in case of a fire can significantly reduce response times and prevent further damage. Additionally, well-trained personnel can perform basic troubleshooting, reducing downtime and maintenance costs by addressing minor issues before they escalate. Ensuring that all staff involved with fire pump systems are adequately trained contributes to overall safety and readiness.

Problem one lower water or no water
1, electric pump reversal will lead to the pump doesn’t produce water.
2, the pump can’t normal water into the same can’t be water, check whether the water bay or check stopcock is blocked or stuck, pumping pipe if there’s a leak will also affect the water into the water.
3, the pump internal corridor of the wear and tear or connection out, check the pump and motor coupling wear and tear, loose and impeller is worn.

Problem two ：
1 、 Check the power force as described over, including connectors, switches, fuses,etc.
2. Check whether the impeller in the pump is jammed by foreign objects
3. A burnt motor will also affect the launch of the pump.

Problem three the water affair is big for a while and small for a while
1. still, the lack of depth down the well may beget this problem, If the pump is a submersible pump.
2. The inflow rate of the pump is too high and needs to be replaced with a suitable pump.

The diesel engine fire pump has the characteristics of good starting performance, serious load operation, compact structure, time-saving and labor-saving maintenance, simple application, and high level of automatic control technology. It is a security monitoring device with reliable performance. The full name of the diesel engine fire pump we usually say is the engineering diesel fire pump set, which can operate at an ambient temperature of -25~55°C, and can be automatically charged, automatically started, and has the functions of automatic alarm and automatic preheating. It is very reliable.

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

Fire pumps are critical components of fire protection systems, and their reliable operation is essential for effective fire suppression. However, like any mechanical equipment, fire pumps can experience various issues over time. Some common problems associated with fire pumps include:

There is a combination equipment that uses diesel as fuel for firefighting, but it is usually used as a backup firefighting facility, because it can only be started automatically when the firefighting signal comes, and the electric water pump fails or the power supply is cut off, that is, the diesel engine firefighting pump set. It is very different from the electric fire pump in that it has its own independent power supply and storage system.

The ZWX box-type non-negative pressure water supply equipment is a pressurized water system designed to address inadequate municipal water pressure in critical settings such as hospitals and hotels, where water cannot be shut off. It also serves as an ideal solution for meeting the domestic water needs of high-rise buildings and, specifically, fulfilling the water requirements of schools. This equipment ensures a continuous water supply, even during maintenance or emergency situations, effectively resolving the challenges posed by low water pressure. With its efficient pressurized water supply and advanced control technology, the ZWX equipment offers stable water pressure and flow rates, catering to the diverse demands of different settings. Furthermore, its intelligent operation and energy optimization contribute to reduced energy consumption.
