What are some best practices for maintaining diesel fire pumps in optimal condition?

Fire pumps are part of the applied water supply and are powered by electricity, diesel. They activate when the pressure in the fire sprinkler system drops below a certain level and provide a flow of water to the sprinkler system at very high pressure, which is then discharged onto the fire.

“Fire-fighting gas top-pressure water supply equipment is usually composed of basic components such as air-pressure water tanks, control cabinets, top-pressure gas storage systems, and decompression release devices; in the fire-fighting state, compressed gas is charged into the air-pressure water tank to replace the fire-fighting water storage in the tank. , and always maintain the rated working pressure of fire protection, and the fixed fire water supply equipment that supplies water to the fire pipe network.”

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The large-scale EDJ electric diesel dual-drive fire pump is a fire-fighting water supply equipment designed and manufactured by Beide Technology Co., Ltd. according to the <> standard, and has obtained 3CF certification. There are many models of Baide dual-power fire pumps, which can be customized according to needs.
Large-scale EDJ electric diesel dual-drive fire pump Pumps for various fire hydrants, sprinkler fire main pumps; suitable for various fire pressurization and voltage stabilization pumps; various villas, residential areas and other fire protection systems; industrial and civil building fire protection System; suitable for various oil depots, oil product loading and unloading terminals, logistics parks and other places with high fire protection level requirements.

The dual power fire pump is composed of a fire water pump, a double shaft extension motor and a diesel engine. One end of the output shaft of the double shaft extension motor is connected to the input shaft of the fire pump, and the other end of the output shaft of the double shaft extension motor is One end of a clutch is connected, and the other end of the clutch is connected with the output shaft of the diesel engine. The fire water pump, the double-shaft extension motor, the clutch and the diesel engine are all fixed on the base. The double shaft extension motor, the clutch and the diesel engine are respectively electrically connected with a control circuit through an action drive circuit. With dual-power fire pumps, there is no need to configure a second fire pump, which reduces floor space and saves manufacturing costs.

EDJ fire pump is a kind of electric and diesel engine dual-drive fire water supply equipment designed and manufactured by Better Technology Co., Ltd. according to the <> standard, and has obtained 3CF certification. Better dual-power fire pump has many models and can be customized according to needs.

A fire pump is a crucial component of a fire protection system that provides the required water pressure to deliver water to the fire sprinkler system or other firefighting equipment, ensuring an adequate supply of water in case of a fire emergency.

Dual power fire pump has high efficiency, remarkable energy-saving effect, compact structure, low noise, small floor area, saving investment and energy, and has obtained UL certification.

Fire pump system comprises a combination of electric motor driven fire pump+diesel engine driven fire pump+electric motor driven jockey pumps+ control panel and other accessory.

1. Inspect and test the fire pump, piping, valves, and relief valves annually for proper operation and water flow.

2. Make sure the fire pump is in good working condition and that all safety systems are in place and operational.

3. Check the fire pump’s pressure gauge and make sure it’s properly calibrated.

4. Inspect the motor, couplings, and belts for proper alignment and condition.

5. Clean the fire pump’s suction and discharge strainers regularly.

6. Ensure that the fire pump is properly lubricated and that all bearings and seals are in good condition.

7. Test the fire pump with a certified flow test annually.

8. Inspect the fire pump’s control panel and make sure it’s in proper working order.

9. Test the fire pump’s jockey pump and make sure it is operational.

10. Check all electrical connections and wiring for proper operation.

1. Electric fire pump: various end suction pumps and split pumps.
2. jockey pump: vertical, small flow, higher lift than electric or diesel pumps.
3. Control panel: Automatically control the water pump with overload and overcurrent protection.
4. Accessories: suction pipe, discharge pipe with flange, battery, gate valve, check valve, flexible expansion joint, pressure switch, pressure gauge, base, etc

This is a set of EDJ fire pump set, which consists of electric pump + diesel pump + jockey pump. The three pumps are automatically started and stopped. When the joceky pump detects that the electric pump cannot operate normally, the diesel engine pump will start automatically. Can also be used, the fire pump set is widely used in various emergency firefighting occasions.

The Max Power-2000kw-10KV Split Case EDJ Fire Pump Set is a cutting-edge fire protection solution that combines power, efficiency, and reliability. With a remarkable power output of 2000 kilowatts and a 10-kilovolt system, this fire pump set delivers unmatched water flow capacity and electrical performance. Its advanced Split Case design ensures easy maintenance and optimal performance, making it suitable for a variety of applications. Engineered to exceed industry standards, the Max Power-2000kw-10KV Split Case EDJ Fire Pump Set offers dependable fire protection in the most demanding environments. Invest in this state-of-the-art solution and experience the pinnacle of fire safety technology.

High quality and low price fire pump, factory direct sales, professional production and sales team, actively and properly solve customer feedback after-sales problems.

The electric pump of the EDJ fire pump group is the main pump, the diesel engine pump is the backup pump, and the jockey pump plays a role in the stabilization of the whole system. When the electric pump fails or the mains is cut off, the control cabinet will receive electricity from the The signal from the contact pressure gauge will start the diesel engine pump within 5 seconds, and reach the rated working condition within 20 seconds to ensure the normal operation of the fire extinguishing work.

In order to match the service cycle of the fire pump, the inspection of the diesel engine and the fire pump should be regularly checked, and the parts to be replaced or repaired should be adjusted and corrected in a timely manner. We need to check the fuel tank reserves and oil quality of the diesel engine fire pump every day; the usage of the battery; the cooling system, etc., the pump shaft, impeller, bearing, and the wear of the water pipe and filter screen of the water pump. (Diesel engines of different brands may be different, and should be checked and maintained according to the specific model and structure of the diesel engine).

With proper maintenance, a fire pump can last 15-20 years or longer. However, components such as seals, bearings, and impellers may need replacement during this period.

The National Fire Protection Association (NFPA) has established standards and guidelines governing the installation and maintenance of fire pumps. NFPA 20, the Standard for the Installation of Stationary Pumps for Fire Protection, provides comprehensive requirements for fire pump design, installation, testing, and maintenance.

Compliance with NFPA 20 standards is essential to ensure that fire pump systems are installed and maintained in a manner that meets nationally recognized safety practices. These standards help ensure the reliability and effectiveness of fire pumps in protecting lives and property during fire emergencies.

It’s a customized EJ fire pump set consisting of electric pump, jockey pump along with control panel, and accessories. It is equipped with priming tank for doing negative suction.

XBC diesel engine fire pump set is the latest according to the national standard GB6245-2006 “fire pump performance requirements and test methods”. This series of products has a wide range of lift and flow, and can fully meet the fire water supply in various occasions such as warehouses, docks, airports, petrochemicals, power plants, liquefied gas stations, textiles and other industrial and mining enterprises.

The minimum fire rated pressure of ED small fire fighting package set water supply equipment is 3 bar and the minimum fire rated capacity is 25 GPM. ED small fire fighting package set water supply equipment includes at least two power or power source driven pumping unitspressure tanks,pipesvalves and accessories measurement and control instruments,control cabinetsoutdoor rain coveretc.

It depends on the type of fire pump and the specific design of the system. Generally speaking, most fire pumps should be set to automatic mode in order to ensure that they operate when needed. However, in some cases, manual mode may be more appropriate and necessary.

Packaging and delivery

Packaging details: standard export wooden cases or as required delivery detail: within 30 days

Specification

Compact structure, stable performance
Install and maintain conveniently
Mechanical or packing seal

Application

Use in fire system water supply, and also suitable for water supply plant, irrigation, drainage pumping plant, electric plant, air conditioning water supply, industry water supply, fire system, shipping industry, oil refining system, mining and other water supplying situations.

1. Make sure the fire pump is regularly inspected and tested according to the manufacturer’s recommendations.

2. Inspect all electrical components and wiring to ensure they are in good working order.

3. Ensure the fire pump is properly lubricated and any worn parts are replaced.

4. Check the suction and discharge valves for proper operation.

5. Inspect the motor and its bearings for signs of wear or damage.

6. Test the fire pump for pressure, flow, and suction.

7. Clean the fire pump, its components, and the surrounding area regularly.

8. Ensure any repairs or maintenance is done by a certified technician.

CDL stainless steel vertical multistage pump is especially suitable for boiler feed water, and can also be widely used in pressure vessel water supply, hot water circulation, high-rise building water supply, farmland irrigation, fire pressurization, hydraulic flushing, food, brewing, medicine, chemical industry, aquaculture , environmental protection, chemical process and machine tool supporting industries, as the power equipment for water supply and drainage.

The diesel engine fire pump is suitable for unattended emergency water supply systems. The product has the characteristics of good technology, high degree of automation, superior performance, complete protection functions, reasonable structure, simple installation, and high cost performance. pipe network pressure.

Diesel pumps can be combined with electric pumps, jockey pumps, etc. to form an automatic water fire-fighting water supply system, and can be linked with the fire control center.

When the pump set receives the starting command, if the mains power is cut off, the automatic control cabinet of the diesel engine will immediately send a start signal to the starting motor of the pump set to start the motor to start the diesel engine at idle speed, and then gradually adjust the throttle to accelerate the diesel engine to the rated speed . The control system will automatically monitor the operation of the diesel engine, such as the oil pressure, oil temperature, speed of the diesel engine, outlet pressure of the water pump, etc., and determine whether the diesel engine starts normally through automatic monitoring. If the start fails, the control system will send a restart signal, and if the three starts fail, the automatic control system will send a failure alarm. When the pump set receives a signal that the pressure of the pipeline network is restored or the mains power is restored to normal, the pump set will quickly slow down and stop automatically after monitoring the idle position for a period of time.

The basis for the selection of fire pumps should be based on the process flow, water supply and drainage requirements, and be considered from five aspects, namely, liquid delivery volume, device lift, liquid properties, pipeline layout, and operating conditions. Fire pumps are mainly divided into vertical and horizontal types. The flow rate of the conveying liquid is one of the important performance data for pump selection. It is directly related to the production capacity of the entire device. The working conditions of the fire pump: flow rate: 2～1400m3/h, Head: 5～130m, maximum working pressure of the system: ≤1.6MPa, working temperature: -15℃～+80℃.

The diesel engine (can be equipped with a clutch) is combined with the fire pump through a highly elastic coupling to form a fire pump unit. The unit also includes diesel tanks, cooling water tanks, fans, control panels (for automatic units) and other components.
When the unit is automatically controlled, the split or diesel engine automatic control cabinet (programmable) realizes the automatic start, input, and automatic switching of the system (switching from the electric pump group to the diesel engine pump group or from this group of diesel engine pump groups to another group of diesel engines) pump set), automatic protection (diesel engine overspeed, low oil pressure, high water temperature, three start failures, low oil level, low battery voltage and other alarm shutdown protection) and other functions, and can also interface with the user’s fire center or automatic fire alarm device, Realize remote monitoring.

The diesel engine fire pump has automatic, manual and fault self-inspection functions. It can monitor the working status of the whole process, restore the fault start, automatic pre-lubrication and preheating automatic restart function, and make the equipment start safer and more reliable. It has the functions of central control room remote control, remote transmission control and field bus connection. The battery is fully automatic floating charging (constant current, constant voltage, trickle charging) mode to ensure that the battery is in a standby state at any time. The diesel engine fire pump is easy to use, equipped with remote transmission meters and meters, which can be connected to the control center as needed, easy to install and use, and easy to maintain.
